Product Details:
|
| Product Name: | Aluminum Roofing Gutter Sheet Roll Forming Machine Downpipe Usage | Control System: | PLC |
|---|---|---|---|
| Warranty: | 2 Years | Life Time: | More Than 10 Years |
| Material: | PPGI/ GI | Botttom Frame: | 360H Steel |
| High Light: | cold roll forming machine,profile roll forming machine |
||
Aluminum Roofing Gutter Sheet Roll Forming Machine Downpipe Usage
Application
The roll formed product is mor durable than the tranditional ppc pipe, and not easy to aging.
It will make the project more integrate, and help enhancing the image of all project.
Drainpipe bending machine used for bend the roll formed pipe, to connect the drainpipe and the elbowed pipe.
Working flow
Decoiler----feeding----roll forming----cut to length----output table
Machine components
De-coiler------------------------------------------1set
Forming machine--------------------------------1set
Pressing die---------------------------------------1set
Cutting device -----------------------------------1set
PLC control box ---------------------------------1set
Hydraulic pump station-------------------------1set
Production support table-----------------------1set
Parameter
| Profile |
1. feeding width 300-800mm 2. material thickness 0.3-0.8mm
|
| 2. Process flow |
Decoiling--feeding---forming---measuring---cutting---production
|
| 3. Decoiler |
5 tons manual decoiler |
| 4.Forming device |
1. Shaft material 45# steel; outer diameter 80mm; 2. Number of rollers : 18 rollers 3. Transport: by chains and gears 4. Forming speed: 10-16m/min 5. Motor: 5.5kw 6. Dimension:8200*1450*1500mm 7. Weight: 5.3t |
| 5. Cutting device |
1. Blade Material: Cr12 steel with quenched treated 60-62°C 2. Cutting system: stop then cut, full automatic |
| 6.Controlling device |
1. screen: text screen displayer
2. PLC: Taida DVP14ES from Taiwan
|
| 7. Hydraulic |
1. Advanced hydraulic system from Taiwan
2. Power: 5.5kw
|
| 8. Spare parts |
1. easy damaged parts: conk 2 pcs, fuse-link 4 pcs 2. rubber mat 1 pcs; 3. bolt spanner 1 pcs |
CUT-OFF DEVICE
Material for Cut-Off Modular:Cr12 steel
Hardness for Heat Treatment:HRC55 – 60℃
Motor: 3kw
Type: hydraulic mould cutting
ELECTRONIC CONTROL SYSTEM
Type: PLC Frequency Control System with touch screen
PLC Brand: Delta
Encoder Brand: Omron
Length Error: ±2mm
Language: English and Chinese
Voltage: 380v/50HZ, 3Phase (it depends on customer requirement)
