Large Image :  Hydraulic Cutting Metal Cold Hat Purlin Roll Forming Machine , Material Thickness 1-3mm

Product Details:

Place of Origin: Hebei,China
Brand Name: CHBEST
Certification: CE,BV,SGS
Model Number: YX-215

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: Standard
Delivery Time: 35 work days
Supply Ability: 15 sets/month
Contact Now
Detailed Product Description
Name: Hydraulic Cutting Metal Cold Hat Purlin Making Roll Forming Machine Warranty: 2 Years
Voltage: 380v Roller Materian: Gcr15
Material Thickness: 1-3mm Color: As Your Require

Hydraulic Cutting Metal Cold Hat Purlin Making Roll Forming Machine



Machine components list:



Name NO. Unit
1.De-coiler 1 set
2.Forming machine 1 set
3.Cutting device 1 set
4.PLC control box 1 set
5.Hydraulic pump station 1 set
6.Production support table 1 set



Technical Parameters:



No Item Parameter Remark
1

Suitable



Material

Type Galvanized Steel
Width 450mm According to customer's requirement
Thickness(mm) 1-3mm According to customer's requirement
2 Forming Speed(m/min) 15

don’t include punching

3 Roller Material Gcr15 steel with hard chromized
4 Cutting Model Hydraulic Cutting According to customer's requirement
5 Power source Type 380V/3PH/50HZ

According to customer's requirement





Machine Details:



LEVELING DEVICE


(1)Thickness: 1-3 mm
(2)Rollers for Leveling: 5 rollers
(3)Material for Rollers: GCr15 steel
(4)Hardness for Heat Treatment: HRC58 – 62°



ROLL FORMING MACHINE



(1)Rollers: 15Groups

(2) Hardness for Heat Treatment: HRC58 – 62°

(3)Frame panel thickness: 20mm

(4)Bottom frame: 40# H-section steel
(5)Motor Power: 5.5kw

(6)Driven type: 1"Chain



CUT-OFF DEVICE


(1)Material for Cut-Off Modular:Cr12 steel
(2)Hardness for Heat Treatment:HRC58 – 62°
(3)Cut-Off Type: Hydraulic, Automatic Cut-Off
(4)Cut-Off Modular:1 set



PLC CONTROL BOX


(1) Type: PLC Frequency Control System with touch screen
(2) PLC Brand: Delta
(3) Encoder Brand: Omron

(4)Length Error: ±2mm

(5)Language: English and Chinese

(6)Voltage: 380v/50HZ, 3Phase (it depends on customer requirement)



HYDRAULIC PUMP STATION



(1) Motor power: 3 kw
(2)Oil type: 46# hydraulic oil
(3) Pump brand: China brand



PRODUCTION SUPPORT TABLE



(1) No power type
(2)Length: 2m



Loading and Packing:



Hydraulic Cutting Metal Cold Hat Purlin Roll Forming Machine , Material Thickness 1-3mm



Our Service:

① If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
② Without visiting, we will send you user manual and video to teach you to install and operate.
③ If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.



Factory Information:



Cangzhou Best Machinery Manufacturing co., LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer,has a professional engineer for technical guidance.Engineers engaged in cold bending mechanical equipment design for more than 20 years,has a wealth of design concept.Can provide users with a special type of design and manufacture.At the same time to sell equipment for installation,guidance,production,commissioning one-stop service.



Hydraulic Cutting Metal Cold Hat Purlin Roll Forming Machine , Material Thickness 1-3mm
