Product Details:
|
| Raw Material Thickness: | 0.2-0.8 Mm | Rolled Material: | Cold Rolled Steel Sheet |
|---|---|---|---|
| Rollers Number: | 16 Groups | Diameter Of Shaft: | 40 Mm |
| Bottom Frame: | 350 H Steel | Motor Power: | 5.5 Kw |
| Driven Type: | 1.0' Chain | ||
| High Light: | profile roll forming machine,metal stud roll former |
||
Construction T Grid Cold Rolling Steel Bar Making Machine Ceiling Roll Forming Machine
We supply the Complete roll forming lines for Ceiling T Grids of Suspension System, T-bars in the various models and sizes, Flexibility in the choice of the sizes, of the pitches and of profiles section, Possibility to produce also complex profiles, with special shapes and systems with or without clip; Average or high productivity lines; Dedicated or combined lines for the production of both Main Runners and Cross-T; Innovative solutions for any level of skill.
Working Flow of Roll Forming Machine
Uncoiling—Feeding&Leveling--Roll forming—Cutting—Products collecting
Main Components
| 3 ton passive de-coiler | 2 sets |
| Hydraulic punching device | 3 sets |
| Main roll forming machine | 1 set |
| PLC Control box | 1 unit |
| Hydraulic station | 1 unit |
| Locking device for joints | 1 unit |
| Out table | 2 units |
1. DECOILER
(1) Max. Width: 500mm
(2) Inner Diameter: Φ450 – Φ550 mm
(3) Out Diameter: 1500 mm
(4) Max. Loading Capacity: 3000 kgs
2. ROLL FORMING MACHINE
(1) Rolled Material: Cold Rolled Steel Sheet
(2) Material Thickness: 0.2-0.4mm
(3) Rollers: 16 Groups
(4) Material for Rollers: Cr12 steel
(5) Material for shaft: 45# steel(quenching and Harding and chroming)
(6) Hardness for Heat Treatment: HRC55 – 60
(7) Diameter of shaft: 40mm
(8) Frame panel thickness: 20mm
(9) Bottom frame: 36# H-section steel
(10) Motor Power: 5.5kw
(11) Driven type: Chain
5. CUT-OFF And PUNCHING DEVICE
(1) Material for Cut-Off Modular:Cr12 steel
(2) Hardness for Heat Treatment:HRC55 – 60
(3) Cut-Off Type: Hydraulic, Automatic Cut-Off
(5) Material for punching die: Cr12steel
(4) Power: 5.5kw
4. PLC CONTROL BOX
(1) Type: PLC Frequency Control System with touch screen
(2) Length Error: ±1mm
(3) Language: English and Chinese
(4) Voltage: 380v/50HZ, 3Phase (it depends on customer requirement)
5. HYDRAULIC PUMP STATION
(1) Oil type: 46# hydraulic oil
(2) Pump brand: China brand
(3) Power:5.5kw+3kw
6. PRODUCTION SUPPORT TABLE
(1) No power type
(2)Length: 2m
Profile of product
Machine Photo:
| Working conditions | |
| 1. Machine size | 10m x 1.2m (L XW) |
| 2. Working size | 20m x 2.5m (LXW) |
| 3. Power supply | 8.5kw |
| 4. Frequency | 50-60HZ |
| 5. Wires/cables | 4-6mm²(length according to workshop) |
| 6. Labor cost | 2 workers |
| 7. Tools | Spanners and screwdriver |
| 8. Lift device | 3-5t forklift or crane |
