IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance

IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance
IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance

Large Image :  IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance

Product Details:
Place of Origin: China, Hebei
Brand Name: CHBEST
Certification: CE.ISO
Model Number: CHBEST-850
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD+6500+SET
Packaging Details: Standard
Delivery Time: 35days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 15sets/month

IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance

Description
Name: Africa High Quality IBR Roof Making Machine Sheet Roll Forming Machine Color: As Yourrequire
Material: GI Control System: PLC
Shaft Material: 45# Steel Warranty: 2 Year
High Light:

roofing sheet making machine

,

metal sheet roof roll forming machine

Africa High Quality IBR Roof Making Machine Sheet Roll Forming Machine





Different roof panel forming machines can produce different shapes of steel roof wall sheets according to the client's profile drawings and requirements. The steel roof, wall sheets are new building materials with various thickness and colors. The finished products are used as the roof and walls of gymnasiums, airports, theatres, factories, warehouses, garages, exhibition centers etc.
The complete machine includes the uncoiler, main forming machine, computer controlling system and run out tables.





No.
Name
Qty
1.
De-coiler
1 Set
2.
Roll Forming Machine
1 Set
3.
Hydraulic Cutting Device
1 Set
4.
PLC Control Box
1 Set
5.
Output table
1 Set





Decoiler

Max. Width: 1250 mm
Inner Diameter: Φ450 – Φ550 mm
Out Diameter: 1500 mm
Max. Loading Capacity: 5000 kgs

Type: Manual Or Hydraulic (Optional)



Roll Forming Machine

Material Thickness: 0.7-1.5mm

Rollers: 28groups

Material for Rollers: 45# steel polished and coated with chrome HRC55-60°

Shaft Diameter: 90mm

Frame panel thickness: 20mm

Bottom frame: 35# H-section steel
Motor Power: 2*11kw

Driven type: 2.0"Chain





o. Parameter
1 raw material suitable material colored steel coil, galvanized coil, aluminum coil
feeding width 1200mm
effective width 988mm
thickness 0.3-0.8mm
PS: the feeding&effective width can be any according to your need.
2 rollers material 45#steel
rows 20 rows
3 shafts material 45#steel, solid ones
diameter Φ90mm and 120mm
4 cutting blade hydraulic cutting, Cr12 Mov
5 capacity 15-20m/min, can be faster as your need.
6 weight 13Tons
7 control system PLC control system with inverter inside to assure the working precision within 1mm
8 dimension 11500*1600*1550mm
9 machine base 400mm H beam
10 middle plate 20mm
11 chains double1.2 inch
PS: the above are for reference, we can design accordin







Working Flow

Decoiler------feeding -------roll forming------cut to length-----output table

IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance 0



Packing Detall



Packaging
Size
123 (L) * 456 (W) * 789 (D)
Weight
1.2 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.


Company Profile

Cangzhou Best Machinery Manufacturing co., LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer,has a professional engineer for technical guidance.Engineers engaged in cold bending mechanical equipment design for more than 20years,has a wealth of design concept.Can provide users with a special type of design and manufacture.At the same time to sell equipment for installation,guidance,production,commissioning one-stop service.



After-Sales-Service

If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.

Without visiting, we will send you user manual and video to teach you to install and operate.



Other Product



Main Features

1.We can make and design all kinds of roll forming machine according to customer's requests.
2.This is a very perfect and durable equipment. We have more than 20 years experiences.
3.This kind of machine has the best quality and the best price. It has accurate measurement and easy operating.
4.We can design and manufacture the special type machine according to the customers' requirement and we could provide technical guiding, production, installation, debugging and maintenance service to all customers.
5. Our product has been exported to many regions and won high reputation because of the high quality and reasonable price.

IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance 1

IBR Roof Making Machine / Roofing Sheet Roll Forming Machine Stable Performance 2
