Product Details:
|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Voltage: | 380V 50Hz 3phases |
|---|---|---|---|
| Condition: | New | Ile Type: | Colored Glaze Steel |
| Use: | Floor | Certification: | CE/ISO9001 |
| High Light: | panel roll forming machine,cold roll forming machine |
||
Main Specifications of Floor Deck Forming Machine
| Raw material | Galvanized steel sheets with strength 325Mpa |
| Material Thickness | 0.8-1.2mm |
| Material Width | 1220mm (depend on profile) |
| Decoiler | Manual or Hydraulic type |
| Roller stand | about 24 stations (Depend on final design) |
| Shaft diameter | 90mm |
| Roller material | Gcr15 steel, quenched and heated process, HRC58-62 |
| Shaft material | First grade 45# steel, heated and quenched |
| Main motor power | 22KW |
| Hydraulic station power | 3.0KW |
| Forming speed | 10-12m/min |
| Cutting type | Hydraulic cutting |
| Blade material | Cr12 quenched treated |
| Hydraulic pressure | 10-12Mpa |
| Controlling system | PLC |
Main Specification of Floor Deck Forming Machine
| Suitable Material | Thickness of coil sheet | 0.8-1.2mm |
| Coil width | Custom-made, 1000mm or 1200mm or 1250mm | |
| Yield strength | 250-350Mpa | |
| Material | Galvanized steel sheet | |
| Decoiler / Uncoiler | Uncoiler type | Manual or Hydraulic or Auto Type |
| Coil width | Max.1250mm | |
| I.D | 508-610mm | |
| O.D | Max.1500mm | |
| Floor Deck Roll Forming Machine | Forming Stations | about 24 stations (Depend on final design) |
| Roller material | Gcr15 steel, quenched and heated process, HRC58-62 | |
| Drive type | Chain transmission | |
| Forming speed | 10-12m/min | |
| Main power | 22KW | |
| Cutting Device | Cutting type | Hydraulic cutting |
| Cutting die material | Cr12Mov steel, HRC58-62 | |
| Cutting tolerance | +/-1.5mm | |
| Encoder | OMRON Brand | |
| PLC Electrical Control Board | PLC | PANASONIC Brand |
| Inverter | YASKAWA Brand | |
| Touch screen | PANASONIC | |
| Operation type | Touch screen & Button | |
| Hydraulic Station | Hydraulic Station | Famous Chinese Brand |
| Hydraulic power | 4.0KW | |
| Hydraulic pressure | 10-12Mpa | |
| Runout Tables | Table type | Simple nonpower type |
| Function | To support the finished panels |
Introduction of Metal Deck Forming Machine
|
1. Floor deck is a lightweight decking system, for car pack construction, comprising steel profile, top-reinforced by concrete. Floor deck roll forming machine is the essential manufacturer of its production.
|
| 2. The Floor Deck Roll Forming Machine is with fully automatic control system with PLC.
|
| 3. Length, quantity of sheets is adjustable. |
|
4. We also can do a custom roll forming machine, i.e. We can design the machine according to your specification and profile drawing.
|
|
5. One roll forming machine only can produce one profile.
|
Main Components
| Decoiler | 1 Unit |
| Feeding | 1 Unit |
| Main roll forming machine | 1 Unit |
| Hydraulic cutting device | 1 Unit |
| Hydraulic station | 1 Unit |
| PLC Computer Control | 1 Unit |
| Output table | 1 Unit |
Flow Chart of Floor Deck Roll Former
Decoiler ---- Feeding guide Device ---- Roll Forming ---- Cutting Device ---- Support Table
Our Advantage
1. Durable and widely used products
2. Simple to operate when assemble
3. Direct manufacturer, provide with high quality and best price.
4. Provide sample in free.
5. Products and design solution supplied fast and freely
6. Best design oriented for your special requirements
