Product Name: Pallet Storage Rack Upright Shelf Profile Roll Forming Machine Supermarket Machine Speed: 8-10m/min
Driven System: Chain Control System: PLC
Cutting Type: Hydraulic Warranty: 2 Years



Pallet Storage Rack Upright Shelf Profile Roll Forming Machine Supermarket




Machine Component

De-coiler------------------------------------------1set
Forming machine--------------------------------1set
Cutting device -----------------------------------1set
Punching machine-------------------------------1set
PLC control box ---------------------------------1set
Hydraulic pump station-------------------------1set
Hydraulic punching device---------------------1set
Production support table-----------------------1set


Profile



Pallet Storage Rack Upright Shelf Profile Roll Forming Machine For Supermarket



Requirements of raw material:

Item NO. Item specification
1 Raw material Processing material: GI or aluminum or steel sheet





2 Thickness 1.5-2.0mm
3 hardness 550 MPA---350 MPA
4 Feeding width accorfing to your requirment
5 Forming speed: about 15 m/min



Process flow



Decoiling--feeding---punching----forming---cutting---production







Parameter



Un-coiler System

Usage: It is used to support the steel coil and uncoil it in a turntable way.

Passive uncoil pulled by roll forming system

Loading capacity: 3.0T

Uncoiling width: 300mm

Inner diameter: 450-550mm



Forming device

Feature : Ensure stability , precision and lifetime.

Length of the main part: about 3300*800*1400mm

Weight of main part: 3 tons

Voltage : 380V/50HZ3Phase (as customer's request)

Roller fixer : Guide column

Frame : middle plate welded

Memorial arch frame type

Frame thickness:25mm

Drive mode: gear or chain

Material of rollers: GCr12MoV

Material of shafts: 45# steel with tempering

Diameter of shafts: φ90mm

Number of rollers : 13rollers

Main power: 7.5kw(Cycloidal planetary gear speed reducer)



Cutting device

1. Blade Material: Cr12 steel with quenched treated 60-62°C

2. Cutting system: stop then cut, full automatic



Controlling device

1. screen: text screen displayer

2. PLC: Delta



Hydraulic

1. Advanced hydraulic system from Taiwan

2. Power: 5.5kw



Spare parts

1. easy damaged parts: conk 2 pcs, fuse-link 4 pcs

2. rubber mat 1 pcs;

3. bolt spanner 1 pcs


Machine Photos


 Pallet Storage Rack Upright Shelf Profile Roll Forming Machine For Supermarket



Pallet Storage Rack Upright Shelf Profile Roll Forming Machine For Supermarket



Pallet Storage Rack Upright Shelf Profile Roll Forming Machine For Supermarket




After-sales service



Technical Support



Fully providing technology supports both within and after the warranty period. Feed back to our customers at the first time.



Spare Parts



Promptly providing spare parts and wearing parts.



Upgrade



Improve technology and upgrade of equipments.
