Name: Color Coated Top Roll Ridge Cap Roll Forming Machine With Pressing Device Coil Width: 350mm
Speed: 4-6m/min Main Power: 3kw
Hydraulic Power: 3kw Bottom Frame: 350H Beam

Color Coated Top Roll Ridge Cap Roll Forming Machine with Pressing Device



Machine Parameters



No Item Parameter
1 Material feeding width 925~1220mm
2 Material thickness 0.3~1.0mm
03 Uncoiler Manual Uncoiler
04 Loading weight 5ton
05 Forming speed 4-6m/min
06 Forming Steps 14stations
07 Shafts materials 45# high quality steel
08 Shafts diameter 70mm
09 Roller materials 45# high quality steel, hard chrome coated 0.05mm
10 Transmission Chains-sprockets
11 Main motor power 11kw
12 Cutting blade Cr12 with quenched treatment 60-62
13 Hydraulic power 5.5kw
14 This machine will automatically measure and cut the length and quantity as per clients set on the PLC touch screen
15 Length cut Accuracy ±1mm
16 PLC control system Omron Japan
17 Frequency converter TAIAN
18 Screen TouchWin
19 Voltage 380V/50HZ/3Phase
20 Total weight Approx 6.2t
21 Overall dimensions 8600x1500x1300mm



Decoiler

It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand.



Forming machine

Put the raw material(steel plate) through the beach to manufacture and process, it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron.



Control system

The target piece`s length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one. The system is easy to operate and use.



Hydraulic oil pump

Hydraulic oil: 46#

hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job



Out put table

It adopts welded steel and supported roller to transmit the products,which is used to collect the finished products.



Color Coated Top Roll Ridge Cap Roll Forming Machine with Pressing Device



Color Coated Top Roll Ridge Cap Roll Forming Machine with Pressing Device



Color Coated Top Roll Ridge Cap Roll Forming Machine with Pressing Device



Installation:

① If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
② Without visiting, we will send you user manual and video to teach you to install and operate.
③ If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.
