Product Details:
|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Warranty: | 1 Year |
|---|---|---|---|
| Color: | As Your Request | Type: | Fully Automatic |
| Raw Materia: | Eps | Application: | Producing Wall Panel |
| High Light: | eps sandwich panel production line,eps sandwich panel machine,32kw Sandwich Panel Production Line |
||
Weight: 1/8 of solid brick wall
Intensity : C30
Heat conductivity : 1/3 of solid brick wall
Sound wave conductivity :1/4 of solid brick wall
Reduce wall cost 15% ~ 20%
Adjust the indoor humidity automatically, save space, reduce pollution
Improve construction efficiency 3 times or 5 times
Simple operation and convenient installation
| Description | sandwich panel production line specification |
| Main motor power | 32kw |
| Equipment overall dimensions | 45000*3000*2800mm |
| Total weight | About 15.5 tons |
| Processing speed | 4-8m/min, continuous stepless adjusted, variable frequency speed regulation, digital display |
| Thickness of up and down steel plate | 0.2-0.8mm |
| Product width | 1000mm,1200mm,1250mm |
| Material | EPS |
| Product thickness | 20-300mm |
| Installed capacity | 25kw |
| Annual output | 600 thousand square meters |
| Power supply | AC380/50-60HZ |
| Production capacity | 0-280 square meters/h if the skillful worker can produce 400 square meters/h |
| Shower set | Can be adjusted in the range of 40-320mm and has ruler indication |
| Down cutter | Can be adjusted in the range of +/-200mm opposite to the up cutter |
Polystyrene cold roll sandwich panel eps foam sheet roll formng making machine production line component
| Roll forming machine | 1 set |
| Hydraulic cutter | 1 set |
| Electrical control system | 1 set |
| Hydraulic system | 1 set |
| Normal run out table | 3 PC 1m*1m |
| Manual de-coiler | 1 set MAX.loading 5T |
