Power Palisade Fence Post 0.3mm Custom Roll Forming Machine Gcr15 Roller

Power Palisade Fence Post 0.3mm Custom Roll Forming Machine Gcr15 Roller
Power Palisade Fence Post 0.3mm Custom Roll Forming Machine Gcr15 Roller Power Palisade Fence Post 0.3mm Custom Roll Forming Machine Gcr15 Roller

Large Image :  Power Palisade Fence Post 0.3mm Custom Roll Forming Machine Gcr15 Roller

Product Details:
Place of Origin: China
Brand Name: CHBEST
Certification: CE, BV, SGS
Model Number: YX-50
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD33000-USD85000/set
Packaging Details: 20GP/40GP container
Delivery Time: 5-60days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20set/month
Contact Now

Power Palisade Fence Post 0.3mm Custom Roll Forming Machine Gcr15 Roller

Description
Name: Power Palisade Fence Post Roll Forming Machine Popular In Africa Material: Galvanized
Control System: PLC Warranty: 2 Years
Customized: Yes Place Of Origin: Hebei, China
Roller Material: GCr15 Weight: 2650kg
Usage: Building Production Capacity: 10-15m/min
High Light:

0.3mm custom roll forming machine

,

gcr15 roller custom roll forming machine

,

power palisade fence post roll former

Power Palisade Fence Post Roll Forming Machine Popular In Africa



1. Product Description

Our steel palisade fencing roll forming machine for different models based on different designs or customer's samples.It is a new building material, the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center.It has many advantages, such as easy installation, short building period, beauty, light weight but high strength.



2. Technical Parameters

No.
steel palisade fencing roll forming machine
1
Suitable to process
Color alu-zinc steel strips
2
Roller
15 Rows plus leveling device
3
Dimensions
5.8*1*1.5m
4
Motor Power
3Kw
5
Pump Station Motor
4Kw.Lichao Brand
6
Thickness of the plate
0.3-0.8mm
7
Productivity
10-15m/min
8
Material of the cutting blade
Cr12,Quenched treatment 58℃-60℃
9
Diameter of the roller
Φ70mm
10
Weight
About 2600kgs
11
Main structure of the machine
Square steel frame
12
Processing precision
Within 1.0mm
13
Side panel of machine
16mm
14
Chain Wheel and Cycle Chain
1 Inch
15
Voltage
380V 50Hz 3phases or as customer's need
16
Control system
PLC control (Delta)
17
Frequency system
Delta
18
Drive mode
Gear driver
19
Touch screen
Delta
20
Rolling materials
45# forging steel with chromium plate
21
Length Tolerance
±2mm



3. Components of the machine

No Name Quantity Remarks
1 Decoiler   1set Up to customer
2 Main Machine Leveling Device 1set
Punching Device 1set
Roll Forming 1set
Post Cutting 1set
Hydraulic System 1set
3 Electric Control System 1set
4 Supporter 2pcs Up to customer



Manual decoiler

Usage:It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand. Loading
capacity:5T,Inner diameter: 500-508mm



Feeding table
Put the raw material(steel plate) through the beach to manufacture and process, it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron.



Main rollers
Material of rollers:High grade 45# Forging Steel ,roller surfaces polishing, hard plating , The polished surface and the heat treatment towards the molds also can keep the molding plate surface smooth and not easy to be marked when it is being stamped.

Control Cabinet
PLC:Delta PLC(or according to customer's inquirement) Touch Screen:Delta Frequency system:Delta Chinese/English and other language



Motor driver
Main motor size :3Kw

Brand: The famous brand from Jermany or according to customer's need



Hydraulic station power
Hydraulic station power: 4Kw

Cutting head
It adopts the Motor drive and automatic location to decide the dimension and cut the target products. Material of blades: Cr12,quenching treatment

Received goods table
It adopts welded steel and supported roller to transmit the products,which is used to collect the finished products. 2 pieces 3meters


4. Why choose this machine?

1 Lifetime seivices
2 Introduced Mitsubishi PLC with touch screen to machine controll system.
3 One worker operation (minimum)
4 Lifetime>10years: roller cover with 0.05mm chrome
80mm diameter solid steel shaft
Cutting blade with heat treatment.
5 Cr12 mould steel cutter with quenched treatment.
6 Product cut-to-length.
7 Technician overseas installing and training available



5.  Our Service

1) Free technical support and free accessories supply.

2) Engineer available to service machinery overseas.

3) One year warranty is provided.

4) Long life technical guidance for free.

5) We always offer technical support, quick response, all your inquire will be replied in 24 hours.
