|Product Name:||Metal Roofing Sheet Double Layer Making Roll Forming Manufacturing Machine||Machine Power:||4kw+3kw|
|Shaft Diameter:||70mm||Warranty:||2 Years|
|Life Time:||More Than 10 Years||Color:||Blue|
|Key Selling Word:||Low Price|
roofing sheet making machine,
metal sheet roof roll forming machine
|2.||Roll Forming Machine||1 Set|
|3.||Hydraulic Cutting Device||1 Set|
|4.||PLC Control Box||1 Set|
|5.||Hydraulic Pump||1 Set|
|6.||Output table||1 Set|
|Type||Manual type(standard)||Hydraulic type(option)|
|Capacity||Max 5tons||From 5-15 tons|
(1)Material Thickness: 0.3-0.8mm
(3)Material for Rollers: 45# steel polished and coated with chrome HRC55-60°
(4)Material for shaft: high grade No.45 steel after treatment
(5)Diameter of shaft: 70mm
(6)Frame panel thickness: 14mm
(7)Bottom frame: 36# H-section steel
(8) Motor Power:3kw
(9)Driven type: 0.6＂Chain
bearing sliding type
|Blade material||Cr12mov quenching and grinding|
the whole bottom frame is grinding for high-precision
|Blade processing||wire-electrode cutting, but the upper balde can not be straight. this is technology|
|Length||1.5m-2m||6m or 12m|
(1) Type: PLC Frequency Control System with touch screen
(2) PLC Brand: Delta
(3) Encoder Brand: Omron
(4)Length Error: ±2mm
(5)Language: English and Chinese
(6)Voltage: 380v/50HZ, 3Phase (it depends on customer requirement)
1) Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.
2) Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly
3) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. AOFA is ALIBAB’s Gold supplier with BV assessment and CE certificate.
4) Q:What can you do if the machine broken?
A: Our machine's warranty period is 18months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.
5) Q:Can you be responsible for transport?
A:Yes,please tell me the destination port or address.we have rich experience in transport.
6) Q:Can you supply the raw materials?
A:Yes,we can supply the galvanized steel coil,galvalume steel coil,color steel coil,and aluminum coil.
