Product Name: Heavy Duty Cutting To Length Roll Forming Machine PLC Control System Color: Blue Or As Your Request
Driven System: Chain Or Gear Box Cutting Type: Hydraulic
Warranty: 2 Years Life Time: More Than 10 Years
High Light:

cold roll forming machine

,

profile roll forming machine



Heavy Duty Cutting to Length Roll Forming Machine PLC Control System


Process flows:



slitting----- separate unit and damping institution-----recoiler



Consist part:



Name Qty.
Hydraulic decoiler 1set
Slitting 1set
Separate unit and damping institution 1set
recoiler  1set



Machine capacity:

Thickness of coiled plate: 0.6-1.5mm

Width of coiled of plate: 1500mm

Precision of slitting: width tolerance about 0.5mm

Length tolerance about 2mm



Machine detail:

1. Slitting

1.1Function: orientation and feeding arrangements around the brush, to achieve positioning strip points and cut the time to stop beating strip to improve the accuracy of sub-shear.

1.2 Power section: dynamic seat, motor, tooth distribution box, universal couplings, clutches and so on.

Main machine parts: fixed arch, movable arch, movable arch mobile device, pressing the knife shaft synchronous lifting mechanism, the trimming device, up and down knife shaft, blade, spacers, frequency conversion motor (11KW), supplied with imported guide and guard, on the device and wipe the brush thin material damping mechanism, welded base and so on. Supplying six blades and spacers, rubber ring set, sub-shear specifications provided by the user.

(1) Number of blades: 7blades

(2) Main power: 11kw

(3) Speed: about 10m/min

(4) Diameter of axis: 150mm

(5) Material of slitting blade: CR12

(5) Hardness of blades: HRC55-60℃

(6) The blade size: 120mm*15mm

(7) Voltage: 380V/3PH/50HZ(or depends on customer’s requirement)

(8) Control system: PLC



2. Separate unit and damping institution

2.1 Function: Separating the steel sheet which after slitting, to adapt the material recoil. When cutting thin material to build the back pull, so that later recoiled strip neat.

2.2 Slitting shaft, mechanical manual pressure device, damping felt

3. Recoiler

3.1 Function: main machine cooperate with first slitting and second separate to recoil the finished product which after slitting, coil win ding tension and winding speed both can be adjustable.

3.2 Base, shaft, rack, wedge-type sizing mechanism, hydraulic shrink oil cylinder, hydraulic station (2.2KW) inverter motor (30KW) and gear box, shaft material pressure points.

(1) Inner Diameter: Φ508 – Φ610 mm
(2) Out Diameter: 1500 mm
(3) Max. Loading Capacity: 10T

(3) Power: 30kw

(4) Type: hydraulic



After-sales service

Technical Support

Fully providing technology supports both within and after the warranty period. Feed back to our customers at the first time.

Spare Parts

Promptly providing spare parts and wearing parts.

Upgrade

Improve technology and upgrade of equipments.
