Product Details:
Place of Origin: China Hebei
Brand Name: CHBEST
Certification: CE/BV/SGS
Model Number: XY38x24
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 25000 / SET
Packaging Details: plastic film for naked machine
Delivery Time: 30-40 days
Supply Ability: 20 sets/month

Power 8.5kw Wall Angle Roll Forming Machine 50-60HZ Frequency 2 Years Warranty

Description
Product Name: Power 8.5kw Wall Angle Roll Forming Machine 50-60HZ Frequency 2 Years Warranty Control System: PLC
Cutting Type: Flying Saw Warranty: 2 Years
Lifetime: 10years No. Roller: 14
High Light:

steel stud roll forming machine

,

metal stud roll former

Wall Angle Roll Forming Machine 50-60HZ Frequency 2 Years Warranty

Light steel keel forming machine with steel as a raw material, by continuous cold rolling molding to produce complex profiles section, type multiple, versatile. We can according to customer design, manufacture different specifications of cold-formed, paint unit equipment.



Machine Components



Name NO. Unit
1. De-coiler 2 set
2. Forming machine 1 set
3. Punching device 1 set
4. Cutting device 1 set
5. PLC control box 1 set
6. Hydraulic pump station 1 set
7. Production support table 1 set



Parameter



1. Manual Decoiler part

Usage:It is used to support the steel coil and uncoil it in a turnable way.
Passive uncoil pulled by roll forming system





2. Coil feeding part

Usage:Put the raw material(steel plate) through the beach to manufacture and process,
it can guarantee that the products are neat, parallel and everything is uniformity.
Please refer to the equipment regulation to know the function of locate angle iron.



3. Main roll forming machine part

Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor
reducer drive, chain transmission,roller was chromed which can keep the molding plate surface
smooth and not easy to be marked when it is working





4. Automatic cuttting system part

It adopts the hydraulic drive and automatic encoder to cut the accurate length you set on the computer.The tolerance is within 10m±1mm
Material of blades: Cr12 quenched
Power supply : hydraulic power
Components:It contains one set of blade, one hydraulic tank and one cutter machine



5. Computer controlling part

1). PLC brand: Normally, it is Delta. Mistubishi, Panasonic, Siemens are optional.
2). working model: fully automatic and manaul
3). working language: normally are English, Chinese,Russia. Can be set as per your requirements.



6. Hydraulic station

1). including one motor,one oil tank,one magnetic valve,one pressure gage, hydraulic oil tube
2). 3kw,4kw,5.5kw,will be adopted as per your profile sheet.



Power 8.5kw Wall Angle Roll Forming Machine 50-60HZ Frequency 2 Years Warranty 0Power 8.5kw Wall Angle Roll Forming Machine 50-60HZ Frequency 2 Years Warranty 1Power 8.5kw Wall Angle Roll Forming Machine 50-60HZ Frequency 2 Years Warranty 2





Working conditions
1. Machine size 10m x 1.2m (L XW)
2. Working size 20m x 2.5m (LXW)
3. Power supply 8.5kw
4. Frequency 50-60HZ
5. Wires/cables 4-6mm²(length according to workshop)
6. Labor cost 2 workers
7. Tools Spanners and screwdriver
8. Lift device 3-5t forklift or crane





Re-sale Service :

1. Send you invitation letter, if you want to visit our factory and check the machines.
2. Good Quality + Competitive price + Quick Response + Reliable Service.
Selling Service :
1. Email the production schedule and make prompt delivery.
2. Count the cheapest shipping cost, look for the fastest forwarder and send relevant documents promptly.
3. Be here for your service at any time.
After-sale Service :
Any questions, contact us by WhatsApp or Telephone.
