8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine

Certification
China Cangzhou Best Machinery Co., Ltd certification
I'm Online Chat Now

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine
8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine

Large Image :  8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine

Product Details:
Place of Origin: China
Brand Name: CHBEST
Certification: CE,BC,SGS
Model Number: YX-1020
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD5500-25500/set
Packaging Details: 20GP/40GP container
Delivery Time: 5+60days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20sets/month

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine

Description
Name: 8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine Raw Material: GI,PPGI
Voltage: 380v Weight: 4.5t
Color: Customized Pperate Style: Automatic
Warranty: 2years Use: Roof
Power(W): 3+3kw Condition: New
High Light:

roofing sheet making machine

,

metal sheet roof roll forming machine

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine



1. Main Parameters:

No. Item Specification
1. Can Formed Material PPGI,GI,AI
2. Equipment operation Automatic
3. Voltage 380V 50Hz 3Phase or as your requirement
4. Thickness of sheet (mm) 0.3-0.8mm
5. Material width(mm) 914/1000/1219/1250mm
6. Cover Width of the sheet after formed As profile drawing
7. The size of the roll forming machine 7500mmx1700mmx1300mm
8. Speed 8-12m/min(also have high spped)
9. Diameter of shaft 70mm
10. Weight of the Machine 4000-4500KGS
11. Material of rollers No. 45 steel quenched and chromed
12. Motor brand Siemens or China brand
13. PLC Siemens or Delta or Mitsubushi
14. Total power (kw) 3+3KW
15 Power of hydraulic system 3KW
16. Power of main molding core 3KW



2. Working Flow:



Manual decoiling----feeding and guiding----roll forming----punching----cut to length----run out table

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 0

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 1



3. Product Application

Different roof panel forming machines can produce different shapes of steel roof wall sheets according to the client’s profile drawings and requirements. The steel roof, wall sheets are new building materials with various thickness and colors. The finished products are used as the roof and walls of gymnasiums, airports, theatres, factories, warehouses, garages, exhibition centers etc.
The complete machine includes the uncoiler, main forming machine, computer controlling system and run out tables.



8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 2





4. Our Service:

1). Payment Term: 30% of the total contract value paid by T/T as down payment, the rest 70% of the total contract value to be paid by T/T after inspection by buyer in seller’s factory while before delivery.

2). Delivery Time: The seller guarantees the equipment will be ready for shipment within 30working days after receipt of deposit from the buyer.

3). Service: We could send the technician to your country to fix the machine if you need.



4). Warranty: 24 months During the warranty, the replaceable parts are free, but the buyers need to pay for the shipping fee.

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 3

5. Packing:



Standard Export Packing.

1. One 40ft container for loading one set machine with manual decoiler;
2. The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.

8-12m/min Production Capacity 3kw Roofing Panel Roll Forming Making Machine 4







6.​ FAQ

Q: Are you manufacturer?
A: Yes, we are manufacturer.

Q: What kind of payment term you can do?

A: We are flexible about payment terms, please contact us for details.

Q: What info you need before you make the proposal for a roll forming machine?
A: The profile drawings, material informations, your special requirements.

Q: What I should do if I just start to know roll forming machinery?
A: Contact us immediately, we provide free consultant pre-sales service.
Q: How to visit our company:
A: 1.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.

2. Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours),then we can pick up you.
3. Fly to Guangzhou aiport: By air From Guangzhou to Beijing airtpot; By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.
