460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty

Certification
China Cangzhou Best Machinery Co., Ltd certification
I'm Online Chat Now

460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty

460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty
460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty 460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty 460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty 460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty

Large Image :  460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty

Product Details:
Place of Origin: China
Brand Name: CHBEST
Certification: CE,BV,SGS
Model Number: YX-460
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD6500-25500/set
Packaging Details: 20GP/40GP container
Delivery Time: 5-60days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20sets/month

460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty

Description
Name: 460 Join Hidden Standing Seam Metal Roofing Sheet Roll Forming Machine Power(W): 4+4kw
Condition: New Use: Roof Building
Warranty: 2 Years Raw Material: GI,PPGI,AL
Place Of Origin: Hebei,China Color: As Your Request
Customized: Yes Voltage: 380V 50Hz 3phases
High Light:

roofing sheet making machine

,

metal sheet roof roll forming machine

460 Join Hidden Standing Seam Metal Roofing Sheet Roll Forming Machine





Working Flow:

Decoiling--Feeding--Guiding--Roll forming--Cut to length--Output table




Technical Detail

A Sheet Specifications

1 Coil Type PPGI GI
2 Width 610mm
3 Thickness 0.3-0.8mm
4 Yield stress Q235
5 Effective 460mm



B Components Details

Roller Material High grade 45# steel. Hard chrome plating, 0.05mm.
Main Frame 350# steel. More stable and no shaking.
Middle Plate

16mm. We use thicker plates to ensure stability

of our products.

Forming Steps 15, according to the drawing.
Shaft Material Φ70 mm, high grade 45# steel.

Treating process: tempering- finish turning,

high rigidity, hard to deform.

Cutting

Blade Material

Cr12, hardness HRC60-62.
Treating process: heat treatment- plane abrasion- wire electrode cutting.



C. Electric Components

Suitable Power 380V, 50 Hz, 3 phase or according to your need.
Screen 7 inch touch screen, easy to operate.
PLC Delta DVP 14ES

well-adapted to various conditions, such as moisture,

electromagnetic disturbance.

Frequency Converter

Delta VFD-M. It has the advantage of slowing down before cutting,

to ensure the length accuracy (±1mm,

far better than industrial standard ±3mm).

Length

Measurement Device

Omron, made in Japan.
It features with high accuracy and stability.



Our Service:

Terms of Payment: 30% of the total contract value paid by T/T as down payment, the rest 70% of the total contract value to be paid by T/T after inspection by buyer in seller’s factory while before delivery.

Delivery: 30 days after receipt of advance payment

Service: we send technician to your country to fix the machine.The buyer should bear all the cost including: visa, Round trip tickets and suitable accommodation, also buyer should pay salary.

Warranty: 18 months limited warranty

During warranty: parts are free but buyer pay for the shipping fee.



FAQ:

Q1. What's your payment terms and delivery time?
A1: 30% as the deposit by T/T in advance, 70% as the balance payment by T/T after your inspect the machine well and before delivery. Of course your payment terms are acceptable.

After we get down payment, we will arrange production. About 30-45 days for delivery.

Q2. Do you have after-sales support?
A2: Yes, we are happy to provide advice and we also have skilled technicians available across the world.

Q3. Do you sell only standard machines?
A3: No, most of our machines are built according to customers specifications, using top brand components.
Q4. What will you do if the machine is broken?
A4: We provide 18 months free warranty and free technical support for the whole life of any machine.
If the broken parts can't repair, we can send the new parts
replace the broken parts freely, but you need pay the express cost by yourself. If it is beyond the warranty period, we can negotiate to solve the problem, and we supply the technical support for the whole life of the equipment.

Q5. Can you be responsible for transport?
A5: Yes, please tell me the destination port or address. we have rich experience in transporting.

Q6. How to visit your company?
A6: 1) Fly to Beijing airport, By high speed train From Beijing Nan to Cangzhou Xi (1 hour).
2) Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.

460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty 0



Loading:

460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty 1460 Join Hidden Standing Seam Roofing Sheet Roll Forming Machine 2 Years Warranty 2
