Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed

Certification
China Cangzhou Best Machinery Co., Ltd certification
China Cangzhou Best Machinery Co., Ltd certification
Customer Reviews
i am happy with Cangzhou BEST Machinery Co.,Ltd. very professional and reiable factory. They offer good quality machine and good sales serverice, look forwarder to cooperate with them again.

—— Moyo

Cangzhou BEST Machinery co.,ltd's machine very good, and production is fast, delivery fast. very turstfull company.

—— Octavio

Thanks for your kindly hospitality. Your company is very professional , we will have nice cooperation in the near future.

—— Cristian

very good company.through very good communication all problems solved, satisfied with my purchase.

—— Spence

very professional factory, realiable, happy with them

—— Samuel

good sales service, delivery time is fast.good communication.

—— Ali

I'm Online Chat Now

Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed

Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed
Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed

Large Image :  Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed

Product Details:
Place of Origin: China
Brand Name: CHBEST
Certification: CE, BV, SGS
Model Number: YX-850
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD5500-USD25500/set
Packaging Details: 20GP/40GP container
Delivery Time: 5-60days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20sets/month

Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine 8-12m/min Speed

Description
Name: Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine Color: As Your Request
Condition: New Usage: Roofing
Warranty: 2 Years Cutting Type: Hydraulic
Material: PPGI.GI.AL Voltage: 380v
Production Capacity: 8-12m/min Cutting Blade: Cr12 Steel
High Light:

roofing sheet making machine

,

metal sheet roof roll forming machine





Metal Roofing Galvanized Aluminum Corrugated Steel Sheet Forming Making Machine



Processing flow diagram

Manual decoiler→Feeding material into machine→Roll forming machine→Measure length→Hydraulic cutting→Finished Products





Technical parameters

Model number FX- corrugated iron roofing sheet making machine
Rolled material 0.3-0.8mm thickness, aluminum sheet, galvanized sheet, colored steel sheet and various steel plates
Effective width 840mm
Feeding width 1000mm
Forming steps 11 stations
Roller 45# forged steel, hard chrome plating within 0.05mm
Diameter of shaft 70mm
Main motor power 3 kw
Pump power 3 kw
Sprocket chain 1 inch
Drive type by chain
Cutting Blade Cr12, heat treatment 60-62°C
Frequency Converter It has the advantage of slowing down before cutting, to ensure the length accuracy (±1mm, far better than industrial standard ±3mm).
component 1 set of manual decoiler,1 set of main roll forming machine,1 set of computer control cabinet,1 set of hydraulic System,1 set of cutting mechanism,1 set of counter,1 set of output table
Payment terms cash,T/T,L/C.
Delivery time 30 working days



Decoiler 1set

Capacity: 5000kg
Width: 600mm
Inner Diameter: 450-550mm
Outter Diameter: 1500mm
Type: Hydraulic Or Manual(Optional)



Roll Forming Machine 1set

Roller Station: 11steps
Material for shaft: high grade 45# steel polished and coated with chrome HRC55-60°
Frame Panel Thickness: 14mm
Power: 4kw
Shaft Material: 45# steel
Shaft: 70mm

Thickness: 0.3-0.8mm.



Control System 1set

Cut-Off Type: Hydraulic, Automatic Cut-Off
Material for Cut-Off Modular:Cr12 steel after treatment
Hardness for Heat Treatment:HRC55 – 60°
Motor for Hydraulic Stand: 3 kW
Driven: 1 inch chain



Control System 1set

Type: PLC Frequency Control System with touch screen
PLC brand: Japan Panasonic
Encoder brand: Omron
Length Error: ±2mm



Hydraulic Pump 1set

Power: 3kw
Oil Type: 46# hydraulic oil
Pump Brand: China Brand



Output Table 1set

Length: 6m
It is simple and used to load finished product



Our service:

1. we can produce the special machine,send your drawing to us,we can design for you.

2. if you buy our products,we also can help you to purchase the material,like color roll,the price is lower than you buy by yourself.

3. we provide a one year warranty and lifelong technical support, we can send our technicians to you to give you on-site training.

The training period would be for no more than one week with the customer paying for the visa, return ticket, food, accommodations and pay salary everyday.

4. engineers available to service machinery overseas.

5. if you come to visit our factory,we can book the room for you, car pick up to send.

Thanks for visiting our products, if you have interest, pls leave your message, or you can contact us, special design is available!

The real data, the most professional foreign trade team, your best trustable partner.



Our company:

Cangzhou Best Machinery Manufacturing co., LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer,has a professional engineer for technical guidance.Engineers engaged in cold bending mechanical equipment design for more than 20 years,has a wealth of design concept.Can provide users with a special type of design and manufacture.At the same time to sell equipment for installation,guidance,production,commissioning one-stop service.
