Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed

Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed
Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed

Large Image :  Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed

Product Details:
Place of Origin: China, Hebei
Brand Name: CHBEST
Certification: CE.ISO
Model Number: CHBEST-840
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: Standard
Delivery Time: 35days
Supply Ability: 15sets/month

Corrugated Roof Sheet Steel Making Cold Roll Forming Machine With High Speed

Description
Name: Corrugated Roof Sheet Steel Making Roll Forming Machine Hydraulic Cutting Color: As Your Require
Thickness: 0.3-0.8mm Control System: PLC
Cutting Type: Hydraulic, Automatic Warranty: 2 Year
High Light:

roofing sheet making machine

,

metal sheet roof roll forming machine

                             Corrugated Roof Sheet Steel Making Roll Forming Machine Hydraulic Cutting



Working Flow

Decoiler------feeding------roll forming------cut to length-----output table



Decoiler

Width 1250mm

Inner Diameter

450-550mm

Out Diameter

1500mm
Capacity 5000kg
Typw Manual Or Hydraulic



Roll Forming Machine

Material Thickness: 0.3-0.8mm PPGI and GI

Roller Stations: 11groups
Material for Rollers: high grade 45# steel polished and coated with chrome HRC55-60°

Diameter of shaft:70mm

Shaft Material: 45# steel

Bottom frame: 36# H-section steel
Motor Power: 3kw

Driven type: 0.6"Chain
Speed:8-12m/min

Frame panel thickness: 14mm



Cutting Device

Type

Hydraulic, Automatic Cut-Off

Cutting Blade Material

Cr12 steel after treatment Hardness for Heat Treatment:HRC55 – 60°

Power 3kw



Control System

Type

PLC Frequency Control System with touch screen

PLC Brand

Delta

Encoder Brand

Omron

Length Error

±2mm
Voltage

380v/50HZ, 3Phase





Hydraulic Pump

Motor power: 3 kw
Oil type: 46# hydraulic oil
Pump brand: China brand



Output Table

No power type
Length: 2m







Company Profile

Cangzhou Best Machinery Manufacturing co., LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer,has a professional engineer for technical guidance.Engineers engaged in cold bending mechanical equipment design for more than 20years,has a wealth of design concept.Can provide users with a special type of design and manufacture.At the same time to sell equipment for installation,guidance,production,commissioning one-stop service.



Our Service

Pre-Sales-Service

If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.

Without visiting, we will send you user manual and video to teach you to install and operate.

After-Sales-Service

Training how to instal the machine, training how to use the machine.

Engineers available to service machinery overseas.

If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.





Packing Detall

1*40 GP container ; main machine naked and fastened with iron wire in the container.
2. rollers were painted with oil and packed with plastic film.

3. electrics devices be packed with wooden box.for Standard export packing.

4. All Components Fixed by steel wire with Container.





Other Product

roof tile machine, double layer machine, highway guardrail machine, c z purlin machine, ceiling drywall machine, water tube machine, ridge cap machine,water gutter machine, roller shutter door machine, cable tray machine, u guide rail machine, door frame machine, rack upright machine, sandwich panel machine.
