Product Details:
|
| Product Name: | Automatic Ceiling Main And Cross T Grid Bar Wall Angl Roll Forming Making Machine | Control System: | PLC |
|---|---|---|---|
| Cutting Type: | Flying Saw | Warranty: | 2 Years |
| Lifetime: | 10years | No. Roller: | 14 |
| Speed: | 20-25m/min | Raw Material: | 0.18- 0.23mm |
| High Light: | steel stud roll forming machine,profile roll forming machine |
||
We supply the Complete roll forming Production line for producing Grid system, Suspended ceiling grid Ceiling T Grid, suspended ceiling grid, Exposed Ceiling Grid, T-bars, T-grid, Ceiling T grid ceiling, T Runner in the various models and sizes, Flexibility in the choice of the sizes, of the pitches and of profiles section, Possibility to produce also complex profiles, with special shapes and systems with or without clip; Average or high productivity lines; Dedicated or combined lines for the production of both Main Runners and Cross-T; Innovative solutions for any level of skill.
Main T-bar (Tee) Cold Roll Forming Machine consist of Single or Dual Head Type de-coiler, Roll forming main machine, Hydraulic, Automatic Punching and cut-off Device, run-out table, PLC Automatic Control Cabinet.
Cross T-grid cold roll forming machine
Machine Components
| Name | NO. | Unit |
| 1. De-coiler | 2 | set |
| 2. Forming machine | 1 | set |
| 3. Punching device | 1 | set |
| 4. Cutting device | 1 | set |
| 5. PLC control box | 1 | set |
| 6. Hydraulic pump station | 1 | set |
| 7. Production support table | 1 | set |
Parameter
1. Manual Decoiler part
Usage:It is used to support the steel coil and uncoil it in a turnable way.
Passive uncoil pulled by roll forming system
2. Coil feeding part
Usage:Put the raw material(steel plate) through the beach to manufacture and process,
it can guarantee that the products are neat, parallel and everything is uniformity.
Please refer to the equipment regulation to know the function of locate angle iron.
3. Main roll forming machine part
Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor
reducer drive, chain transmission,roller was chromed which can keep the molding plate surface
smooth and not easy to be marked when it is working
4. Automatic cuttting system part
It adopts the hydraulic drive and automatic encoder to cut the accurate length you set on the computer.The tolerance is within 10m±1mm
Material of blades: Cr12 quenched
Power supply : hydraulic power
Components:It contains one set of blade, one hydraulic tank and one cutter machine
5. Computer controlling part
1). PLC brand: Normally, it is Delta. Mistubishi, Panasonic, Siemens are optional.
2). working model: fully automatic and manaul
3). working language: normally are English, Chinese,Russia. Can be set as per your requirements.
6. Hydraulic station
1). including one motor,one oil tank,one magnetic valve,one pressure gage, hydraulic oil tube
2). 3kw,4kw,5.5kw,will be adopted as per your profile sheet.
| Working conditions | |
| 1. Machine size | 10m x 1.2m (L XW) |
| 2. Working size | 20m x 2.5m (LXW) |
| 3. Power supply | 8.5kw |
| 4. Frequency | 50-60HZ |
| 5. Wires/cables | 4-6mm²(length according to workshop) |
| 6. Labor cost | 2 workers |
| 7. Tools | Spanners and screwdriver |
| 8. Lift device | 3-5t forklift or crane |
