Description
Product Name: Profesional Factory Cable Tray Perforated Trunking Making Roll Forming Machine Material Thickness: 0.7-2.5mm
Driven System: Chain Or Gear Box Control System: PLC
Warranty: 2 Years Life Time: More Than 10 Years
Driven Type: 1.5" Chain Certificate: CE And ISO
High Light:

cable tray production line

,

steel profile roll forming machine



Profesional Factory Cable Tray perforated trunking Making Roll Forming Machine



We are the professional ladder type cable tray roll forming machine, our line could be run for cable tray and cover cable tray production, cable ladder, Slotted Cable Tray, the cable tray production line can be custom prepared according to client requirements.



A perforated(ventilated) tray has openings in the bottom of the tray, allowing some air circulation around the cables, water drainage, and allowing some dust to fall through the tray. Small cables may exit the tray through the ventilation openings, which may be either slots or holes punched in the bottom.


Machine Component

Hydraulic De-coiler-----------------------------1set
Forming machine--------------------------------1set
Cutting device -----------------------------------1set
Punching machine-------------------------------1set
PLC control box ---------------------------------1set
Hydraulic pump station-------------------------1set
Hydraulic punching device---------------------1set
Production support table-----------------------1set


Decoiler

Inner Diameter: Φ500 – Φ550 mm
Out Diameter: 1000 mm
Max. Loading Capacity: 5000 kg

Type: hydraulic
Power:7.5kw
Control system: PLC



roll forming machine

Rolled Material: Cold Rolled Steel Sheet
Material Thickness: 1-2mm
Rollers: 22Groups
Material for Rollers: GCr15 steel after treatment


Hardness for Heat Treatment: HRC55 – 60
Frame panel thickness: 20mm
Bottom frame: 40# H-section steel
Motor Power:11 kw x2

Driven type: double sides double row 1.5"Chain

Punching device

Item Parameter detail
Frame processing the whole levelling surface is made by drilling machine
Mould material Cr12mov
Mould processing wire eletrode-cutting for the mould shape, it will save pressure
Hole size According to your request
Hole number According to your request
Pressure 20Mpa


Cutting device

Type

Pre-cutting

Blade material Cr12mov quenching and grinding
Frame processing

the whole bottom frame is grinding for high-precision

Blade processing wire-electrode cutting, but the final product is clean after cutting, the the product shape this is technology
Working Hydraulic type


PLC

Type: PLC Frequency Control System with double touch screen
PLC Brand: FATEK
Encoder Brand: Omron
Length Error: ±2mm
Language: Chinese and English
Voltage:380v 50hz 3phases(as customer requirement)

Hydraulic pump



Main Item Parameter detail
Motor

3kw China brand or according to your request

Pump China brand or according to your request
Solenoid valve China brand or according to your request
Cooling system

Cooling fan
