Product Details:
|
| Certification: | CE ISO SGS | Product Name: | Metal C U Channel Stud And Track Roll Forming Machine For Roof Structure |
|---|---|---|---|
| Control System: | PLC | Cutting Type: | Hydraulic |
| Warranty: | 2 Years | Usage: | Ceiling |
| Material: | GI,AL | Voltage: | 380V 50Hz Or Customized |
| Hardness: | HRC58-62 | Materia Of Cutting: | Cr12Mov |
| High Light: | steel stud roll forming machine,profile roll forming machine |
||
Metal C U Channel Stud and Track Roll Forming Machine for Roof Structure
1. Machine Details
2) Hydraulic stop cutting
Cutting way: Hydraulic cut.
Oil pump station: 1set.
Hydraulic power: 5.5kw hydraulic system.
Blade Material: CR12Mov with heat treatment HRC58-62.
Tolerance: +-1.5mm
3) Control box system
Power supplier: 380V, 50 Hz, Three Phase (adjusted with the requestment)
Length & quantity measurement automatically;
Length & quantity controlled by PLC
Length inaccuracy can be amended easily.
Control panel: Button-type switch and touch screen
The language in the touch screen: English and Chinese
Unit of length: millimeter (switched on the control panel)
4) Finished tables
It adopts welded steel and supported roller to transmit the products.
Size: 4000*1350*1000mm
2. Detailed specification:
| Metal stud and track drywall channel roll forming machine for ceiling | |
| Suitable material | PPGI/Aluminium sheet/galvanized sheet/various sheet plates |
| Thickness of coil sheet | 0.3-0.8mm |
| Coil width | as customer's profile drawing requirement |
| Effective width | as customer's profile drawing requirement |
| Material of main frame | welded by 6mm steel plate |
| Diameter of Soild shaft | 40mm, high grade 45# steel |
| Roller | Cr12 |
| Thickness of middle plate | Memorial archway |
| Forming station | 12 rows |
| Drive type | Gear |
| Power of main motor | 5.5 kw, Lichao, Shanghai, with reducer |
| Forming speed/ | About 25-30m/min |
| Hydraulic pump station | 5.5 kw, 40# hydraulic oil |
| PLC | DELTA(TAIWAN)/Mitsubishi |
| Material of cutting blades | Cr 12, quenching 58-62℃ |
| Frequency converter | It has the advantage of slowing down before cutting, to ensure the length accuracy±1mm, far better than industrial standard ±3mm. |
| Switch | CHNT |
| Frequency changer | Delta,Taiwan |
3. Packing & Delivery
Before loading to the container, we will check the machine first
Second, make some protection on the machine, Such as, we will mpaint the coil on the roller and shaft, in case the roller and shast got corrosion and rusty during long time delivery
Third, we will make the plastic package on the easy damage parts, and fix all the parts into container by the steel wire rope, and ensure the machine will not damage when shaking on sea.
At last, we will take photos for customer when loading to container
4. Our Service:
Good quality: We have a professional designer and experienced engineer team.
Good service: we provide the technical support for whole life of our machines.
Guarantee period: within one year since the date of finishing commissioning. The guarantee covers all the electric, mechanic and hydraulic parts in the line except for the easy-worn parts.
Easy operation:All machine cotrolling by PLC computer controlling systerm.
Elegant apperance:Protect the machine from rust and the painted colour can be customized
Reasonable price:We offer the best price in our industry.
