Product Details:
|
| Product Name: | Galvanized Steel Round Shape Water Tube Profile Making Roll Forming Machine | Warranty: | 2 Years |
|---|---|---|---|
| Machine Speed: | 4-6m/min | Material Thickness: | 0.3-0.8mm |
| Driven System: | Chain Or Gear Box | Control System: | PLC |
| High Light: | downpipe roll forming machine,pipe roll forming machine |
||
Galvanized Steel Round Shape Water Tube Profile Making Roll Forming Machine
Specifications
| Raw material | |
| material spec | sheet, galvanized steel sheet, aluminum sheet |
| thickness of coil sheet | 1mm |
| Machine details | |
| roller material | High grade NO. 45 forged steel with 0.05mm hard chrome plating |
| shaft material | High grade NO. 45 carbon wrought steel |
| cutting blade | Cr12 mould steel with quenched treatment |
| diameter of shaft | 70 mm |
| forming steps | 16 rows |
| productivity | 12 m/min |
| hydraulic station power | 22 KW |
| hydraulic pressure | 10-12MPa |
| controlling system | famous PLC computer control |
| material of cutting table | Cr 12 mould steel with quenched treatment |
| appearance size | 7500mm*1150mm*1510mm |
| hydraulic oil | 40# hydraulic oil |
| Electric tension | 380V 50 Hz 3 Phase or as your requirements |
Manual Decoiler
Dimensions: 1700mm*1000mm*800mm
Width of feeding: 500mm
Capability: 3 Ton
Bound of expand &fight: 420mm—510mm
Mode of expand and fight: inner expand and fight by manual
Way of feeding: manual
Forming section
Profile steel thickness: 0.3-0.8 mm carbon steel and stainless steel
Main motor power: 2 * 5.5 KW, AC motor, side motor to save space ( Brand: Guomao which made in China )
Machine Voltage, Frequency, Phase: 380 V, 50 Hz, 3Phase, ( According to customer’s require )
Roll station:15stations +1 station of rectify
Roller material:SAE1045, hardness and chrome plated surface
Shaft diameter: diameter 65 mm material: SAE1045
Machine roll forming speed: 0-18 m/min
Transmission: by chain, 1.0 inch double line
Hydraulic power: 5.5kW
Working pressure: 12Mpa adjustable
Solenoid valve: 1 group
Hydraulic oil: 46 # hydraulic oil
Color: Blue ( or base on customer request )
Control box:
1)Programmable setting of profile length and quantity
2)Automatic stopping of the equipment after completion of the cutting programme.
3)Operating system language: English and Chinese
4)Computer used to control length & quantity. Machine will automatically cut tolength and stop when required quantity is achieved
5)PLC brand: Panasonic
6)Frequency converter brand: Yaskawa, quantity: 1
7)Touch screen: Taiwan Weinview
Packing Method
Main machine is nude; the computer control box is packed by carton box
Transportation
All machines need one 40 feet container to hold
Payment Term
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Delivery Time
Within 50 days after receiving deposit
Service &Warranty:
1). We provide our customers with 24 months’ warranty.
2). Any parts damaged due to quality problem shall be changed for free within the first two years.
3). Technical guide is provided during whole life of the machine.
4). Oversea services will be provided but any cost thus incurred will be paid by the buyers.
