Product Details:
|
| Name: | Trapezoidal Roof Sheet Metal Roll Forming Machine Supplier PLC Control | Color: | As Your Require |
|---|---|---|---|
| Material: | PPGI/GI | Control System: | PLC |
| Roller Station: | 11groups | Warranty: | 2year |
| High Light: | roofing sheet making machine,metal sheet roof roll forming machine |
||
Auto 914 PLC Control Metal Roll Forming Roofing Sheet Machine With PPGI/GI
Working Flow
Decoiler------feeding------roll forming------cut to length-----output table
Machine Component
| Decoiler | 1set |
| Roll Forming Machine | 1set |
| Cutting Device | 1set |
| PLC Control Box | 1set |
| Hydraulic Pump | 1set |
| Output Table | 1set |
Company Proifle
Cangzhou Best Machinery Manufacturing co. , LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer , has a professional engineer for technical guidance . Engineers engaged in cold bending mechanical equipment design for more than 20years , has a wealth of design concept . Can provide users with a special type of design and manufacture . At the same time to sell equipment for installation , guidance , production , commissioning one-stop service .
Main parameters
| No. | Main parameter of 914 roll forming machine | |
| 1 | Suitable to process | Color steel plate |
| 2 | Width of the plate | 1000mm |
| 3 | Thickness of the plate | 0.3-0.8mm |
| 4 | De-coiler | Manual one, can load 5 tons raw material |
| 5 | Rollers for forming | 14 rows |
| 6 | Diameter of the roller | 80mm |
| 7 | Rolling material | Carbon Steel 45# |
| 8 | Main motor power | 4kw |
| 9 | Productivity | 8-12m/min |
| 10 | Cutting method | Hydraulic mould cutting |
| 11 | Material of the cutting blade | Cr12 |
| 12 | Hydraulic cutting power | 3kw |
| 13 | Processing precision | Within 1.00mm |
| 14 | Control system | Delta PLC control |
| 15 | Side panel of machine | 14mm |
| 16 | Main structure of the machine | 300 H steel |
| 17 | Weight | About 6.0T |
| 18 | Dimensions | 6.5*1.45*1.3m |
| 19 | Voltage | 220V single phases |
| 20 | Certificate | CE/ISO/TUV |
Company Proifle
Cangzhou Best Machinery Manufacturing co. , LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer , has a professional engineer for technical guidance . Engineers engaged in cold bending mechanical equipment design for more than 20years , has a wealth of design concept . Can provide users with a special type of design and manufacture . At the same time to sell equipment for installation,guidance , production , commissioning one-stop service .
we could provide efficient and satisfactory service for you throughout the period of our cooperation.If necessary , we can supply you with local technical support and send technicians to for installation and operation training .
