Product Details:

• Entry gate will be provided for movement of the sheet to roll former.

• The main base is MS fabricated structure and adequately ribbed to minimize the distortion
• It is accurately machined on top and bottom surfaces the threaded holes are made on the bed for positioning the stands.

• The stands are mounted on the bed of the machine the line alignment can be easily done due to guideways arranged on the bed of the machine
• Each forming head consists of a fixed housing and sliding type outboard housing
• The mill stands will be arranged to locate shafts mounted on taper bearings
• For the top shafts, the bearings are housed in the cartridge type bearing blocks
• The bottom shaft bearings are located in the bored machined in the housings
• The bottom arbors are fixed in a position whereas the top arbors along with cartridge blocks could be raised or lowered in vertical guides machined in housings.

• The roll shafts dia. 70mm will be manufactured from quality steel and will be keyed to locate tooling.

• The drive to the roll former will be by means of a chain
• The main drive will be provided by means of 10 HP motor

• One set of Tooling with EN grade will be from imported material suitable for your machine as standard supply
• The same is involved in operations like rough machining, keyway, rough profiling, profile machining and inspection with a final template for above.

• Hydraulically operated power pack along with cutting die with 3 HP electrical.

Additional Information:

• Pay Mode Terms: T/T (Bank Transfer)
•
