Metal Heavy Gauge 5MM 6MM Guardrail C Post Roll Forming Machine

Large Image : Metal Heavy Gauge 5MM 6MM Guardrail C Post Roll Forming Machine

Product Details:

Place of Origin:	China
Brand Name:	CHBEST
Certification:	CE,BV,SGS
Model Number:	YX-310

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD12500-USD42500/set
Packaging Details:	20GP/40GP container
Delivery Time:	5-60days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Contact Now

Metal Heavy Gauge 5MM 6MM Guardrail C Post Roll Forming Machine

Description

Name:	Heavy Gauge 5MM 6MM Guardrail C Post Roll Forming Machine	Certification:	CE/ISO9001/SGS/CIQ
Raw Material:	Galvanized Sheet	Warranty:	2 Years
Voltage:	380V 50Hz 3phases	Material Of Rollers:	CR 12 Quenched HRC 58-62
Place Of Origin:	Hebei,China	Color:	As Your Request
Speed:	12-15m/min	Customized:	Yes
Highlight:	6MM Guardrail Roll Forming Machine , 5MM Guardrail Roll Forming Machine , heavy gauge guardrail roll former

Metal Heavy Gauge 5MM 6MM Guardrail C Post Roll Forming Machine

Heavy Gauge 5MM 6MM C Post Beam Roll Forming Machine designed for highway guardrail production with precision engineering and robust construction.

Main Accessories & Components

Main Purline Forming Machine
5 Tons Hydraulic Un-coiler
Automatic Guide Device
Hydraulic Motor System (three oil cylinders: two for punching holes, one for pre-cutter)
PLC Computer Controlling System with Touch Screen (Delta, Schneider, or Siemens brands)
Pre-punching Holes Device (customizable hole size)
Pre-cutting Device
Reshaping Device
PLC Automatic Size Adjustment System (60mm to 300mm)
PLC Automatic C to Z Purline Interchange System
Run Out Table (4 units)
Tools and Operation Manual

Technical Specifications

Item	Specification
Coil Width	According to final profile requirements
Rolling Speed	Approximately 8m/min
Rolling Thickness	5-8mm GI up to 550Mpa
Minimum Length	No limit
Control System	PLC and transducer (Mitsubishi)
Un-Coiler	5 ton motorized de-coiler
Flattening System	Upper 3 rollers, down 4 rollers (total 7 rollers)
Roller Stations	Approximately 17 stations
Roller Material	Gcr15
Shaft Material and Diameter	￠100mm, 45# forge steel
Pre-Punching Material	Cr12, hardness HRC 58-62 with chrome coating
Main Motor Power	37KW Siemens
Hydraulic Station Power	11kw with air fan cooling
Cutting Material	Cr12, quenching 58-62℃
Electric Source	415V, 50HZ, 3 phase
Drive Method	Gear box for each station

Quality & Safety Features

Our highway guardrail machine provides enhanced safety features to prevent major personal injuries caused by excessive speed during driving. We utilize first-line international brands and complete all accessory processing and machine assembly in our own factory. This ensures consistent quality and reliable performance for expressway safety improvements.

Comprehensive Service & Support

Professional team handling design, processing, assembly, debugging, and delivery
On-site engineer training available (client covers travel expenses)
Free operator training at our factory
Online video training and operation manual included
2-year warranty on easily broken parts
Lifetime technical service support
Rapid spare parts replacement via DHL (3-day delivery)
Cost-price replacement after warranty period

We provide immediate technical solutions and aim to establish win-win business relationships with our clients worldwide.
