Product Details:
|
| Production Capacity: | 10-15m/min | Condition: | New |
|---|---|---|---|
| Use: | Door | Place Of Origin: | Hebei, China |
| High Light: | 10m/min door frame roll forming machine,0.7mm door frame roll forming machine,10m/min door frame making machine |
||
Material
Material Thickness:0.7-1.2mm
Machine Components
Feed Material Device
2) Main Machine
With feeding material guide, body frame made from H400 type steel by welding
Side wall thickness: Q235 t18mm
Rollers manufactured from 40Cr steel,CNC lathes,Heat Treatment,hard Chrome Coated
Shafts Diameter=ф75mm,precision machined
Gear/Sprocket driving,about 14-step to form
Main Motor=11KW , Frequency speed control
Real forming speed 15-18m/min (Not include cutting time)
Post Hydraulic Punching+Cutting Device
Post to cut, stop to cutting,Two pieces type of cutting blade design, no blanking
Hydraulic motor: 3KW ;Cutting pressure: 0-14Mpa
Cutting tool material:Cr12MoV,Heat treatment to HRC58-62 degree
4)PLC Control System
Control The Quantity And Cutting Length Automatically
Input The Production Data(Production Batch,pcs,Length,etc.)On The Touch Screen ,
It Can Finish The Production Automatically.
Combined With: PLC, Inverter, Touch Screen, Encoder, etc
PLC:Siemens (German brand)/Schneider(French brand)
7-Inch Color Touch Screen:Siemens (German brand)/Schneider(French brand)
Encoder: Omron (Japan brand)
Thermal Relay: Siemens (German brand)/Schneider(French brand)
Air Switch: LG-LS(Korea brand)
Cut-to-Length Tolerance≤±1 mm
Control Voltage 24V
5)Exit Rack: Un-powered, Two Units,with rollers on it for easy movement
After-Sale Service
1. The warranty is 24 months after the client receives the machine.
Within the 24 months, we will courier the replacement parts to the client free of charge
2. We offer technical support for the entire life of our machines
3. We can send our technicians to install and train the workers in the clients' factories with
extra cost
Terms Of Trade
1.Minimum order quantity (MOQ): 1 Set
2.Delivery time: about 45 workdays
3.Port of loading: port of Xiamen
4.Type of payment: by T/T or by L/C
5.Export:to more than 60 countries and regions, including Taiwan, UK, France, Singapore,
Greece, Australia, USA, Mexico, Brazil, Chile, Bolivia, Trinidad, Israel, Saudi Arabia, etc
Packing Style
Packing method: Main body of machine is naked and covered by plastic film(to protect of dust and corrosion),
loaded into container and steadily fixed in container suitable by steel rope and lock, suitable for long-distance transportation.
Producing time: about 45 workdays after received the advance payment
Period of Validity for Price: 30 days from quotation date
Packing method: with nude packing steadily fixed in one 40 feet container suitable for
long-distance transportation
| uitable material | Q235 color steel coils;0.3-0.7mm;1220&1450mm coil width |
| Forming speed | About 10- 25m/min |
| Power Requirement | Main motor power: 5.5 Kw(Depend on final design) |
| Hydraulic station power: 4.0Kw(Depend on final design) | |
| Material of forming rollers | No.45 steel, plated with chrome on surface. |
| Material of cutter | Cr12 mould steel with quench treatment, HRC58-60 |
| Material of shaft | High quality 45# steel, with heat treatment.Roller grinder milling. |
| Shaft diameter | 65mm |
| Controlling system | Mitsubishi PLC & converter |
| Total weight of machine | About 3800KGS |
| Machine's size | About 4.5m×1.0m× 1.2m (Depend on final design) |
| Shipping | 1x40GP container can load one machine |
