Product Details:
|
| Product Name: | Fully Automatic Double Layer Metal Roofing Sheet Machine For Building | Color: | Blue Or As Your Request |
|---|---|---|---|
| Machine Speed: | 8-12m/min | Machine Power: | 3kw+3kw |
| Usage: | Building | Life Time: | More Than 10 Years |
| Tile Type: | Colored Steel | Place Of Origin: | Hebei, China |
| Roll Material: | 45# High Grade Steel | Transmission: | Chain |
| High Light: | 6kw double layer roll forming machine,double layer roll forming machine 12m/min,fullyautomatic gi sheet making machine |
||
Working flow
Decoiler---Feeding--Froming-- Cut to legth--Output table
A Sheet Specifications
| 1. | Coil Type | Pre-painted coil,Galvanized steel,Aluminum |
| 2. | Width | 1200mm |
| 3. | Thickness range | 0.3mm-0.8mm (max) |
| 4. | Yield stress(mm) | Q235 |
| 5. | Effective width | 1000mm |
B Machine Specifications
| 1. |
Power requirement
|
Type | 220v/380v/3ph/50hz | |
| Main Motor power | 5.5kw | |||
| Cutter power | 4kw | |||
| 2. | Forming speed(m/min) | 8-15 | Not include the time of cutting | |
| 3. | Forming stations | 16 | Depend on actual design | |
| 4. | Thickness of structure | 14mm | ||
| 5. | Forming shaft diameter(mm) | 70 | ||
| 6. | Chains | 1 inch | ||
| 7. | Sleeve | 5mm thickness thick wall pipe instead of galvanized pipe | ||
| 8. | Type of cutting | Roll formed and length-set cutting | ||
| 9. | Control system | PLC Panasonic Inverter Schneider | ||
| 10. | Install dimension(depend on the final design) | 7.5m×1.5m×1.2m | Without panel length | |
| 11. | Total weight (Approx) | 4T | Depend on final design | |
| 12. | Screen | Text screen /touch screen | ||
Components of line:
1) Manual De-coiler ------------------------------------------------------ 1 set
2) Guiding Device--------------------------------------------------------- 1 set
3) Roll Forming System--------------------------------------------------- 1set
4) Cutting Device---------------------------------------------------------- 1set
5) Hydraulic System------------------------------------------------------- 1 set
6) PLC Control System-----------------------------------------------------1 set
7) Run out table ----------------------------------------------------------- 1 set
Product features:
- Double layers color steel sheet roll forming machine can produce two designs,this machine process galvanized steel and color steel sheet,thickness is 0.3-0.8mm.
- This machine the best advantage is save space.But three layers can not working in the same time.PLC can choose working by up layer,or down layer.
- We can make Double Layers Color Steel Sheet Roll Forming Machine as your request, our engineer will make drawings before you order.If you have drawing,please offer it to us,our engineer will confirm it and will give advise.
- We are professional in roll forming machines,we have more than 20 years in this area.
After your order
After your order
1. Update manufacturing progress informations per week.
2. Help check competitive shipping company and freight.
3. Help you purchase raw material for testing machine if you need.
After Sale Service
1. Warranty time: 18 months.
2. Our engineer are available service oversea during the warranty time. VISA charge, accommodation, flight tickets, and $100 per day per person by customer.
3. Technical support online for lifetime.
