Steel Wave Profile Corrugated Roofing Sheet Panel Roll Forming Machine Line
Overseas engineers can perform installation, instruction, commissioning, and maintenance.
The machine is controlled by a computer controller program, which can be set in advance to cut the
meter, length, quantity and punching position. The program will perform cut-to-length cutting by itself, saving manpower! With
multi-languages, it is convenient for users in various countries, simple and easy to operate, and can input multiple sets of
different work data, saving time, labor and labor! , High throughput!
2. Technical Parameters:
||Color steel/galvanized aluminum/galvanized
||main motor power
||4KW with Cycloidal reducer
||Hydraulic station power
||Diameter of principal axis
||Material expand width
||Hydraulic cutting type
Usage:It is used to support the steel coil and uncoil it in a turnable way.
Passive uncoil pulled by roll forming system
Loading capacity:5T Uncoiling width:1250mm Inner diameter: 450-550mm
In order to get high quality product, our machine adopts welded steel frame structure, AC frequency conversion motor reducer
drive, chain transmission, roller surfaces polishing, hard plating, heat treatment and chrome coating.
Roller chrome coated thickness: 0.05 mm
Roller material: Forging Steel 45# heat treatment, coated
Panasonic PLC is adopted to organize all actions of the machine. The length of workpiece is adjustable according to the setting of
on the PLC. Two optional control modes: automatic and manual. By automatic mode, the machine can realize fully automatic working.
In order to make the machine has a long service life and easy maintenance; we only adopt globally famous electrical components.
It is derived by a Gear Pump. After filling the hydraulic oil into the hydraulic oil tank, the pump could drive the hydraulic
cylinder to realize the cutting function.
The system includes a set of hydraulic tank, a set of a Gear Pump, two hydraulic pipes .and two sets of Solenoid Valves.
Power of The Pump:4kw
Hydraulic oil :40#
Domestic famous engines, strong driving force, low fuel consumption, high economic benefits 12F+4R sliding sleeve shift.
The blade is cut by laser
Double guide post+Hydraulic drive
Material of Guide post:45#steel quenching is done before heat-treatment,can guarantee the surface smooth and hardness.
1) we can send our engineer to your site and do the training for your men. you just only bear the cost for our engineer's air ticket, visa, accommodations, food and transportation in your country.
2) You can send your men to our factory. we will teach them how to operate the machine without training charges.
3) Actually, there's another cheap and easy way to choose. Every machine leaves our factory with one book of operation manual. You can read through the manual first, and get familiar with the machine. Then we can get a video call, and teach you on-line on how to operate the machine.
4) Apart from the above training course, we also provide 18 MONTH warranty for all the easily broken part of the machine for free and whole-life technical service support.
- 1.Nude,with waterproof cloth and stow-wood.Imported computer control system packedwith waterproof cloth and card board.
- 2.This producing line is maintained free of charge for 18 months.When the machine isused in China,we will install and debug the machine for free;if it is used at abroad,we willsend the professional technician to debug. Buyers should take all the fees for technicianstravelling abroad.
- 3 AlI the parts in the roll forming machine is free to maintain all the life,if in 18 months ourcompany bear the cost for exchanged the broken part like the new parts cost and expresscost,if more than 18 month,we also free to maintain the broken parts but for send the newparts,the buyer need bear the express cost.
- 4.When ship the roll forming machine,We will also send one set CD and specification(Chi-nese and English) to you with the machine,they can teach you how to operater themachines.
We can produce according to your requirements.
