TR4&TR5 Double Layer Roofing Panel Roll Forming Machine
1. Product information:
♠color steel sheet roll forming machine can produce two designs,this machine process galvanized steel and color steel sheet,thickness is 0.3-0.7mm.
♠This color steel sheet roll forming machine the best advantage is save space.But 2 layers can not working in the same time.PLC can choose working by up layer,or down layer.
♠We can make color steel sheet roll forming machine as your request, our engineer will make drawings before you order.If you have drawing,please offer it to us,our engineer will confirm it and will give advise.
♠We are professional in color steel sheet roll forming machine,we have more than 20 years in this area.
2. Machine details:
SPECIFICATIONS FOR ROOF SHEET ROLL FORMING MACHINE
|
|
Raw Material
|
feeding width
|
mm
|
up layer 1000
|
|
down layer 1000
|
|
effective width
|
mm
|
up layer 820
|
|
down layer 836
|
|
thickness
|
mm
|
0.3-0.8
|
|
Main Roll Forming Machine
|
roller material
|
|
45# steel plated with chrome
|
|
diameter of shaft
|
mm
|
70
|
|
roller station
|
steps
|
up layer 16
|
|
down layer 16
|
|
Main Configuration
|
main motor power
|
kw
|
5.5
|
|
hydraulic station power
|
Kw
|
4
|
|
control system
|
PLC brand
|
Mitsubishi
|
3. Machine production process
Drawing confirmation
After confirming the final profile with the customer, the team of 12 engineers worked out detail workable
parts CAD drawings; After 5 recheck, the production manager arrangement the material for all machine parts.
Start production
Our company owns 12sets rough lathe machine, 20sets precise lathe machine, and 30sets shearing machine, all machine parts start to manufacture.
Product Inspection
Our company Own 3sets hard test machine, and 4sets surface thickness Chromium test machine.
Roller and shaft: Our Inspect team test 90% wheels and shafts, confirm all parts size precise and performance after processing. Our Inspect team test all roller surface, confirm all part surface paint above 5um.
Mainframe and medium plate: Our Inspect team tests the mainframe and plate cutting precise.
Assembling machine
5 workers assemble and welding one machine body frame by three days.
Machine painting
Putty ensure weld parts surface smoothly, and environment-friendly paint ensures protect worker body and environment.
Machine Manual use test
Confirm the output sheet tolerance within 2mm.
Cutter production
According to the finally manufacture sheet, confirm the blade precise profile, Cr12 MOV steel cutting knife finished by laser cutting.
Storage
To protect the machine surface clear and without damage, we paint again and package by the film.
4. Why choose us?
| 1. Our company owned a professional design team, we can design different profiles according to customer’s demands. |
| 2. We design and manufacture machines using advanced standard technology. We have strict control over the quality of the machines, our principle is that “never let one unqualified Machine leave our factory”. |
| 3. Our machines are controlled by computer, PLC display, simple operation, stable and reliable operation, durable and maintenance-free. |
| 4. Our machines can uses galvanized steel sheet, colored armor plate or aluminum plate as the material plate. |
| 5. Our machine has a long warranty and you can use it without worry after purchase. |
| 6. After purchasing our machine, we will offer easily damaged parts freely. |
| 7. All use well-known brand appliances. |
| 8. Multilingual control system, including Spanish, Russian, English and Chinese. |
| 9. Powerful teach teams with more than 12 years of working experience will help you, improve the design if it is not perfect before selling. |
| 10. 24*7 hours before and after service in English, Russian, Spanish and others. |
5. Packing
a.The main body of machine with water-proof plastic, then fixed to container by 8mm diameter steel wire and angle iron. b.Rollers and shafts are covered with anti-rust oil. c.PLC control system and motor pump are packed with waterproof paper and plastic film. d.Spare parts in a carton box. e.Manual decoiler was nude packing. f.The output-table put into a carton box. g.If the machine is too long, we will divide it into two parts and pack them in one package with steel wire. h.Fit for ocean shipping.
6. FEATURE OF PRODUCT
More efficient and accurate execution of production orders；
High equipment reliability；
Little waste of materials and energy；
High productivity；
High quality materials, get a longer service life；
All parts of the machine are processed with precision, and the surface of the roll is chromeplated to ensure that customers can get qualified products at the same time, it can avoid the scratch of the color steel surface paint, and increase the service life of the roll；
Customized coil processing solutions to solve all aspects of technical problems.
Raw materials
In order to help customer save time find good supplier for materials: Prepainted galvanized steel coil, galvanized steel coil, galvalume steel coil (Aluzinc coil), aluminium coil and so on, we can directly provide customer high quality coil with compatitive price
We can produce according to your requirements.
