Product Details:
Place of Origin: China
Brand Name: CHBEST
Certification: CE BV SGS
Model Number: YX-850
Payment & Shipping Terms:
Minimum Order Quantity: 1set/month
Price: USD6500-25500/set
Packaging Details: 20GP/40GP container
Delivery Time: 5-60days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20sets/month

C8 1000mm Roofing Sheet Roll Forming Machine Steel Metal Making High Effective

Description
Name: C8 Steel Metal Roofing Sheet Roll Forming Making Machine High Effective Roller Material: Hydraulic Cutting
Feeding Width: 1000mm Cutting Blade Material: Cr12
Material Of Rollers: 45#steel Forge Shaft Material: 45# Steel, Quenched
Effective Width: 850mm Marketing Type: Hot Product 2021
Speed: 8-12m/min Side Panel: 20mm
High Light:

1000mm roofing sheet roll forming machine

,

warehouses roofing sheet roll forming machine

,

1000mm color steel roll forming machine

C8 Steel Metal Roofing Sheet Roll Forming Making Machine High Effective



1. Advantage:

Overseas engineers can perform installation, instruction, commissioning, and maintenance.

The machine is controlled by a computer controller program, which can be set in advance to cut the
meter, length, quantity and punching position. The program will perform cut-to-length cutting by itself, saving manpower! With
multi-languages, it is convenient for users in various countries, simple and easy to operate, and can input multiple sets of
different work data, saving time, labor and labor! , High throughput!

The finished product of Profile Use Metal Steel Tile Roll Forming Machine is widely used in the construction of various industrial plants, villages, warehouses, supermarkets, hotels, exhibition, family construction, shopping malls shutter doors and etc. It has the advantage of beautiful, classical appearance and grace taste.



2. Technical Parameters:

Manual decoiler

Inner diameter:450-550mm

Outer diameter:1500mm

Max Coil width:1500mm

Capacity: 5.0T

Decoiler dimension:1.5*1.5*1.5m

Decoiler weight:355KGS

Quantity: 1set

Usage: It is used to support the steel coil and uncoil

it in a turntable way. Passive uncoil pulled by roll forming system



Computer Control Cabinet       Programmable setting of profile length and quantity,Computed mode has two modes: automatic and manual.The system is easy to operate and use
Language:English, Chinese,Spanish and Russian



Hydraulic System :Oil pump Power:4kw
Hydraulic oil: 46# hydraulic oil
Working pressure: 12-16Mpa adjustable
Solenoid valve:1 groups
Color:Blue (or as customer's request).



Product Stand Main framework adopts welded steel and supported roller,used for transmit and collect the finished products.





3. Machine Details:

Fully automatic tile Roofing Roll Forming Machine is composed of feeding, forming and cutting after forming. The products produced by tile press have smooth and beautiful appearance, uniform lacquer pattern, high strength and durability. It is widely used in industrial and civil buildings, such as factory buildings, warehouses, locomotive garages, hangars, gymnasiums, exhibition halls, cinemas and theatres. Its components include: whole machine, PLC computer control system, hydraulic pump station system, automatic post-shearing system.



4Main Features
1) Roofing Roll Forming Machine adopts high level automatic control software to realize production information management.
2) The automation control system of the whole unit adopts a highly integrated network, which makes the performance of the automation system superior.
3) Color steel tile equipment also has the advantages of operation, maintenance, maintenance and mechanical debugging, mold replacement is easy.



5. Guarantee:

1 we can send our engineer to your site and do the training for your men. you just only bear the cost for our engineer's air ticket, visa, accommodations, food and transportation in your country.
2 You can send your men to our factory. we will teach them how to operate the machine without training charges.
3 Actually, there's another cheap and easy way to choose. Every machine leaves our factory with one book of operation manual. You can read through the manual first, and get familiar with the machine. Then we can get a video call, and teach you on-line on how to operate the machine.
4 Apart from the above training course, we also provide 18 MONTH warranty for all the easily broken part of the machine for free and whole-life technical service support.



6. We want to know following information.

1), What is the exact profile you want to produce?

2), What kind of material you will use, such as steel or aluminium, max coil weight, thickness?

3), What kind of decoiler and stacker you need?

Pls contact us as below informaiton,hope can cooperate,thanks advance





We can produce according to your requirements.
