Product Details:
Place of Origin: China Hebei
Brand Name: CHBEST
Certification: CE/BV/SGS
Model Number: XY56
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: plastic film for naked machine
Delivery Time: 30-40 days
Supply Ability: 20 sets/month

Light Steel Profile C U T Stud And Track Roll Forming Machine Hydraulic Punching

Description
Product Name: Light Steel Stud&Track Steep Profile Roll Forming Machine/C U Machine Punching Type: Hydraulic
Control System: PLC Cutting Type: Flying Saw
Warranty: 2 Years Lifetime: 10years
High Light:

t stud and track roll forming machine

,

hydraulic stud and track roll forming machine

,

punching light steel roll forming machine

Light Steel Stud&Track Steep Profile Roll Forming Machine/C U Machine



Specifications



NO.



1.



Raw material

Type GI&PPGI
Thickness 0.3-0.8mm
Yield strength 235Mpa TO 350Mpa



2.



Decoiler

Operation Manual/Hydraulic for option
Weight apacity 5tons







3.







Main body

Roller station 12 stations
Diameter of shaft 70mm
Material of rollers 45# steel with chrome 0.05mm
Material of shaft 45# steel with chrome 0.05mm
Frame 350mm H-Beam
Chain 1inch



4.



Cutter

Operate Automatic hydraulic type
Blade Material Cr12MOV



5.



Power

Pump motor for cutter 4kw
Main motor 5.5kw
Voltage 380V 50HZ



6.



Control system

Electric Box PLC control system, Inverter, encoder
Language English
7. Speed 8-12m/min



















































































Sales Service

1.Payment Term: 30% paid by T/T as down payment, the rest 70% after inspection by buyer in seller’s factory while before delivery. After finished production, we will inspect the machine and inform the buyer, the buyer send person to inspect goods, then payoff the whole payment before shipping.

2.Delivery Time: We guarantees the equipment will be ready for shipment within 30 working days after receipt of deposit .

3.After sale Service: We could send technician to your country to install machine if you need. The buyer need to pay for extra cost, including: visa, round trip tickets, accommodation, salary of USD 100~120 per day.

4.Warranty: 18 months

During the warranty, the replaceable parts are free, but the buyers need to pay for the shipping . We will also provide you instruction manual to show you how to operate the machines.



Package

a. Need one 20 or 40 ft container, according to your final drawing.

b. The main body of machine is fixed to container by 8mm diameter steel wire, rollers and shaft is

covered with anti-rust oil.

c. Spare parts in carton box.
