**Double Layer Roof Sheet Roll Forming Machine**
**Model: ZW-DL850**
*Ideal for Zimbabwean Markets – High Efficiency, Low Maintenance, and Long Lifespan*

**Key Technical Specifications**

| **Parameter** | **Specification** |
|------------------------------|-----------------------------------------------------------------------------------|
| **Machine Type** | Double-Layer Roof Sheet Roll Forming Machine |
| **Target Market** | Zimbabwe (optimized for local climate & material availability) |
| **Material Compatibility** | **Base Layer**: Galvanized steel (0.3–1.0 mm) / Aluminum |
| | **Top Layer**: PVC, Aluminum, or Pre-Painted Steel |
| **Coil Width** | 800–1200 mm |
| **Production Speed** | 6–20 m/min (adjustable via VFD) |
| **Forming Stations** | 16–20 stations (suitable for common Zimbabwean profiles) |
| **Roller Material** | High-strength alloy steel, anti-rust coating |
| **Thickness Range** | 0.3–1.0 mm (both layers) |
| **Cutting System** | Hydraulic shear with programmable PLC |
| **Cutting Length** | 1–10 meters (±1.5 mm accuracy) |
| **Main Motor Power** | 11–18.5 kW (energy-efficient AC motor) |
| **Control System** | PLC + 7-inch HMI (user-friendly, preset profiles for common designs) |
| **Power Supply** | 380V/220V, 50Hz, 3-phase (adaptable to local grid) |
| **Machine Weight** | ~6–8 tons (compact and robust design) |
| **Dimensions** | 10m (L) × 1.8m (W) × 1.6m (H) |

---

 **Standard Configuration**

| **Component** | **Description** |
|------------------------------|-----------------------------------------------------------------------------------|
| **Dual Decoilers** | Motorized uncoilers with tension control (suitable for 500–600mm coil OD) |
| **Pre-Punching Unit** | Optional for screw holes (common in Zimbabwean roofing) |
| **Roll Forming Frame** | Reinforced steel structure with adjustable rollers |
| **Hydraulic System** | 4.5 kW power unit for cutting and pressing |
| **Output Conveyor** | Adjustable speed belt conveyor (3–12 m/min) |
| **Safety Features** | Emergency stops, safety guards, overload protection |
| **Electrical Cabinet** | Dust-proof and moisture-resistant (IP54 rating) |

---

### **Optional Accessories**

| **Option** | **Description** |
|------------------------------|-----------------------------------------------------------------------------------|
| **Solar-Powered Setup** | Adaptable for off-grid solar systems (popular in Zimbabwe) |
| **Anti-Corrosion Upgrade** | Extra coating for humid/tropical climates |
| **Auto Stacker** | Automated sheet stacking (reduces labor costs) |
| **Localized Training** | On-site installation and operator training |
| **Spare Parts Kit** | Common replacement parts (rollers, blades, sensors) |

---

**Why Choose This Machine for Zimbabwe?**
1. **Adapted to Local Needs**:
- Handles **galvanized steel** (widely used in Zimbabwe).
- Resistant to dust and humidity (suitable for tropical climates).
2. **Cost-Effective**:
- Low energy consumption and minimal maintenance.
3. **Easy Operation**:
- Simple HMI interface with preset programs for popular profiles (e.g., **IBR, Corrugated**).
4. **Durability**:
- Reinforced frame and anti-rust rollers for long-term use.

---

**Contact Us** for customized solutions tailored to your specific requirements in Zimbabwe!

---
