Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control

Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control
Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control
Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control

Large Image :  Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control

Product Details:
Place of Origin: China Hebei
Brand Name: CHBEST
Certification: CE/BV/SGS
Model Number: XY325
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: plastic film for naked machine
Delivery Time: 20-30 days
Supply Ability: 20 sets/month
Contact Now

Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control

Description
Product Name: Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine Color: Blue Or As Your Request
Decoiler Capacity: 5t Cutting Type: Hydraulic
Processing Material: PPGI And GI Life Time: More Than 10 Years
Highlight:

PLC control metal sheet rolling machine

,

self-lock steel roll forming machine

,

color steel roofing sheet machine

Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control
Product Specifications
Attribute Value
Product name Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine
Color Blue or as your request
Decoiler Capacity 5t
Cutting type Hydraulic
Processing material PPGI and GI
Life time more than 10 years
Decoiler Specifications
  • Max. Width: 700 mm
  • Inner Diameter: Φ458 - Φ550 mm
  • Out Diameter: 1500 mm
  • Max. Loading Capacity: 5000 kgs
Machine Components
No. Name Qty
1. De-coiler 1 Set
2. Roll Forming Machine 1 Set
3. Hydraulic Cutting Device 1 Set
4. PLC Control Box 1 Set
5. Hydraulic Pump 1 Set
6. Output table 1 Set
Roll Forming Specifications
Item Parameter detail
Processing Material GI and PPGI
Material thickness 0.25-0.8mm
Machine frame 360#H steel, Adopt diagonal line welding, leveling instrument measurement to make sure the final frame is high-precision
Machine siding panel Plate type: Plate thickness:20mm, Painting:normal painting
Pillar type (option): Pillar thickness:30mm, painting:Chroming
Forming stations 16 stations (according to the profiles)
Machine rollers High grade No.45 forged steel, plated hard chroming with thickness 0.05mm
Processing way: cutting--drilling--CNC lathing--quenching--CNC lathing--chroming
Machine Shaft φ70-80mm high grade No.45 steel after treatment
Machine spacers CNC lathing in high-precision
Machine bearings China Haerbin bearing or SKF international bearing (option)
Driving system 1 inch chain or gear box (option)
Machine power 3kw-11kw (according to the profiles)
Machine working speed 8-12m/min or 10-30m/min (option)
Machine adjust type After machine installation, we will test it ourselves, compare with the profile drawing, the difference is controlled in 0.5mm
Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control 0
Cutting Specifications
Type Details
Bearing sliding type Blade material: Cr12mov quenching and grinding
Frame processing: The whole bottom frame is grinding for high-precision
Blade processing: Wire-electrode cutting, but the upper blade can not be straight (this is technology)
Working: Hydraulic type
Color Steel Self Lock Metal Sheet Rolling Roll Forming Machine PLC Control 1
Output Table Options
Type Length
Manual 1.5m-2m
Auto (option) 6m or 12m
PLC Specifications
Main item Parameter detail
PLC Delta (standard) or according to your request
Inverter China brand (standard) or according to your request
Touch screen Mcgs (standard) or according to your request
Encoder China brand (standard) or according to your request
Voltage/HZ/Phase 380v/50-60hz/3phase
Frequently Asked Questions
Q: Can you make machine according to my design?

A: Yes, we have experienced technical team to work out the suitable design for you and confirm with you until you agree.

Q: Will you deliver the right goods as ordered? How can I trust you?

A: Yes, we will. The core of our company culture is honesty and credit.

Q: What payment terms you accept?

A: 30% deposit and 70% before shipment, and sometimes we can consider more for you as per your request.

Q: What is the warranty for our machine?

A: We have 2 years guarantee, and provide whole life's technical support.
