Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations

Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations
Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations
Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations

Large Image :  Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations

Product Details:
Place of Origin: China, Hebei
Brand Name: CHBEST
Certification: CE/ISO
Model Number: CHBEST-H44
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 14500
Packaging Details: Standard
Delivery Time: 35das
Payment Terms: L/C,D/A,T/T,Western Union,MoneyGram
Supply Ability: 15sets/month
Contact Now

Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations

Description
Name: Steel R Panel Roofing Sheet Roll Forming Machine Hydraulic Cutting High Speed Key Word: Color Steel Profile Roll Forming Machine
Color: As Your Require Material: PPGI GI
Shaft: 70mm Voltage: 380V/50HZ/3PHASE
Warranty: 2 Year Hydraulic Power: 3kw
Highlight:

380V/50HZ/3PHASE Voltage Roofing Sheet Roll Forming Machine

,

2 Year Warranty Steel R Panel Roll Forming Machine

,

25 Roller Stations Metal Roofing Roll Forming Machine

Steel R Panel Roofing Sheet Roll Forming Machine with Hydraulic Cutting
High-speed roll forming machine for steel R panel roofing sheets featuring hydraulic cutting system for precise, efficient production.
Main Structure Features
  • Simple, robust structure with shape-steel construction and screw connectors for enhanced flexibility and strength
  • Premium components from brand-name manufacturers ensure reliable operation
  • Automatic length-fixed forming and cutting system guarantees precise dimensions and distortion-free finished products
  • Easy installation and factory-ready production capability
  • High efficiency operation with low noise output
Work Flow Process
Decoiler → Feeding → Roll Forming → Cut to Length → Output Table
Machine Specifications
Decoiler
Max. Width 1250 mm
Inner Diameter Φ450 - Φ550 mm
Out Diameter 1000 mm
Max. Loading Capacity 5000 kgs
Roll Forming Machine
Material Thickness 0.3-0.8mm PPGI and GI
Roller Stations 25 groups
Roller Material High grade 45# steel polished and chrome coated (HRC55-60°)
Frame Panel Thickness 20mm
Bottom Frame 36# H-section steel
Motor Power 7.5kw
Shaft Diameter 70mm
Shaft Material 45# steel
Driven Type 1.0" Chain
Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations 0
Cutting Device
Cut-Off Modular Material Cr12 steel after treatment
Hardness HRC55 - 60°
Cut-Off Type Hydraulic, Automatic Cut-Off
Hydraulic Stand Motor 3 kW
Steel R Panel Roofing Sheet Roll Forming Machine with 380V/50HZ/3PHASE Voltage 2 Year Warranty and 25 Roller Stations 1
PLC Control Box
Type PLC Frequency Control System with touch screen
PLC Brand Delta
Length Error ±2mm
Language English and Chinese
Voltage 380v/50HZ, 3Phase (customizable)
Hydraulic Pump
Motor Power 3 kw
Oil Type 46# hydraulic oil
Pump Brand China brand
Ordering & Service Terms
  1. Payment: 30% T/T deposit, 70% balance after factory inspection before shipment
  2. Delivery: Ready for shipment within 30 working days after deposit receipt
  3. Installation Service: Available technician dispatch (buyer covers all costs: visa, flights, accommodation, $100-120/day salary)
  4. Warranty: 18 months (free replacement parts, buyer covers shipping; includes operation manual)

Tag:

metal sheet roof roll forming machine,

roofing sheet making machine,

metal roofing equipment
