Product Details:
Place of Origin: China
Brand Name: CHBEST
Certification: CE,BV,SGS
Model Number: YX-828
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD8500-25500/set
Packaging Details: 20GP/40GP container
Delivery Time: 5-60days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20sets/month

House Roof Glazed Tile Roll Forming Machine , Metal Roof Making Machine

Description
Name: Most Popular House Roof Glazed Tile Roll Forming Making Machine Selling Usage: Buidling
Warranty: 2years Voltage: 380v
Speed: 5-6m/min Place Of Origin: Hebei,China
Weight: 4.5t Way Of Drive: 1.0 Inch Single Chain
Power: 7.5kw Control System: PLC Control
High Light:

roof panel roll forming machine

,

steel roof tile forming machine

Most Popular House Roof Glazed Tile Roll Forming Making Machine Selling


1. Machine details:

1) DECOILER
(1) Max. Width: 1500 mm
(2) Inner Diameter: Φ450 – Φ550 mm
(3) Out Diameter: 1500 mm
(4) Max. Loading Capacity: 5000 kgs

2) ROLL FORMING MACHINE
(1) Material Thickness: 0.3-0.8mm PPGI and GI
(2) NO. of roller Stations: 9roller stations
(3) Material for Rollers: high grade 45# steel polished and coated with chrome HRC58-62°
(4) Material for shaft: high grade 45# steel polished and coated with chrome HRC58-62°
(5) Diameter of shaft: 70mm

3) PRESSING AND CUT-OFF DEVICE
(1) Material for Cut-Off Modular:Cr12 steel after treatment
(2) Hardness for Heat Treatment:HRC58-62°
(3) Cut-Off Type:Hydraulic, Automatic Cut-Off
(4) Motor for Hydraulic Stand: 3kw
(5) Press tool material: Cr 12 steel after heat-treated


2. Component:

COMPONENT FOR Roof Sheet Glazed Tiles Roll Forming Machine
Name
Quantity
Units
Decoiler
1
Set
Main Machine
Feeding device
1
Set
Roll forming system
1
Set
Cut Equipment
1
Set
Hydraulic system
1
Set
Electric control system
1
Set
Supporter/Automatic Stacker
1
Set



3. Why choose us?
1. We can make and design all kinds of roll forming machine according to customer’s requests.
2. This is a very perfect and durable equipment. We have more than 20 years experiences.
3. This kind of machine has the best quality and the best price. It has accurate measurement and easy operating.
4. We can design and manufacture the special type machine according to the customers’ requirement and we could provide technical guiding, production, installation, debugging and maintenance service to all customers.
5. Our product has been exported to many regions and won high reputation because of the high quality and reasonable price.

4. FAQ:
1) Are you a factory or trade company?
We are factory, a professional manufacturer,and exporter, one of the biggest manufacturer in North China. We have rich experience in exporting of machinery equipment and our service is also good as the trading company.

2) What machines are you producing?
Automatic purlin machine, channel machine, cable tray roll forming machine, ceiling roll forming machine, corrugated sheet machine, cutting and slitting machine and line, color steel tile roll forming machine, downspout roll forming machine, floor deck roll forming machine, glazed tile roll forming machine,hydraulic decoiler, highway guardrail roll forming machine, light gauge steel frame machine, sandwich panel production line, stone coated tile production line and so on.

3) Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available all around the world. We always need your machines running good in order to keep your business running.

4) How to visit your factory?
Our location is Botou County, Cangzhou City, Hebei Province, China.
Way one: You can fly to Beijing airport, and take the railway from Beijing South to Cangzhou West (1hour only), and then we can pick up you from the railway station.
Way two: You can fly to Shanghai airport, then by high-speed train from Shanghai Hongqiao Railway Station to Cangzhou West Railway Station(4hours), then we can pick up you from the station.

5) What can you do if the machine has any problem?
We have more than 20 experienced engineers, we can give you a correct guide to control the machine, if anything you can’t run it, our engineers are available in any country to serve.

6) Can you be responsible for transport?
Yes, please just tell me your destination port or address, we have rich experience in transport.

7) Is your price is higher than others?
No, as we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality. We can make sure that our machine could use more than 20 years.

8) How long could the machine be made?
From 20days to 50days depending on the profile of the machines. If you urgent need the machines, we try our best to shorten the delivery time.

9) Does one machine can only produce one style panel profile?
Not exactly.For wider and double layer making machine. It can produce more than 6 types of panels.
