Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales

Certification
China Cangzhou Best Machinery Co., Ltd certification
I'm Online Chat Now

Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales

Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales
Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales

Large Image :  Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales

Product Details:
Place of Origin: China, Hebei
Brand Name: CHBEST
Certification: CE/ISO
Model Number: CHBEST-840
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD+8000+SET
Packaging Details: Standard
Delivery Time: 35days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 15sets/month

Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales

Description
Name: Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales Color: As Your Require
Control System: PLC Material: PPGI/GI
Thickness: 0.3-0.8mm Warranty: 2 Year
High Light:

roof panel roll forming machine

,

steel roof tile forming machine

       Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales​



Company Profile

Cangzhou Best Machinery Manufacturing co., LTD is specialized in the manufacture of high-end equipment cold bending forming equipment manufacturer,has a professional engineer for technical guidance.Engineers engaged in cold bending mechanical equipment design for more than 20years,has a wealth of design concept.Can provide users with a special type of design and manufacture.At the same time to sell equipment for installation,guidance,production,commissioning one-stop service.



Machine Component

Decoiler 1set
Roll Forming 1set
Pressing Device 1set
Cutting Device 1set
PLC Control Box 1set
Hydraulic Pump 1set
Output Table 1set



Decoiler

Max. Width: 1500 mm
Inner Diameter: Φ450 – Φ550 mm
Out Diameter: 1500 mm
Max. Loading Capacity: 5000 kgs

Type: Manual Or Hydraulic



Roll Forming Machine

Material Thickness: 0.3-0.8mm

Roller Station: 9 groups

Material for Rollers: high grade 45# steel polished and coated with chrome HRC58-62°

Diameter of shaft: 70mm

Shaft Material: 45# steel

Frame panel thickness: 20mm

Bottom frame: 36# H-section steel
Motor Power: 3kw

Driven type: 1.0"Chain



Pressing Device

Press tool material: Cr 12 steel after heat-treated



Cutting Device

Motor for Hydraulic Stand

3kw

Cut-Off Type

Hydraulic, Automatic Cut-Off

Material for Cut-Off Modular

Cr12 steel after treatment
Hardness for Heat Treatment:HRC58-62°



Control System

Type

PLC Frequency Control System with touch screen

PLC Brand

Delta

Encoder Brand

Omron

Length Error

±2mm

Language

English and Chinese

Voltage

380v/50HZ, 3Phase



Hydraulic Pump

Motor power: 3 kw
Oil type: 46# hydraulic oil
Pump brand: China brand



Output Table

No power type
Length: 2m



Stacker

Type Manual
Auto(option)

Length 1.5m-2m 6m or 12m





Work Flow

Decoiler--------feeding--------roll forming--------pressing and cut to length-----output table

Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales 0



Installation

① If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
② Without visiting, we will send you user manual and video to teach you to install and operate.
③ If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.





Our Advantage



1. We are a factory with nearly 20 years experiences on Roll Forming Machines;
2. We have our own research and development team with strong ability to solve all kinds of problems;
3. We have stable raw material suppliers to ensure the best quality and on time supplying with low cost;
4. We have more than 20 technicians that can go abroad for the after-sale service;

5. We have more than 100 kinds and models products for your choice, you can find the most kind of

roll forming machines from us;

6. We have Laser Cutting Machine, CNC Machining Center, Polishing Line, Painting Line, etc. advanced

production equipments to ensure the quality of each part and the best appearance of our machines;

7. Our machines have reached the International Inspection Standards;
8. We have got the ISO9001:2008 Certificate and CE Certificate;
9. We are always waiting to serve you 7 days a week and 24 hours a day.



Trapezoidal Sheet Metal Roof Aluminum Corrugated Tile Roll Forming Machine Sales 1
