1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming

1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming
1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming 1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming 1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming 1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming

Large Image :  1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming

Product Details:
Place of Origin: China Hebei
Brand Name: CHBEST
Certification: CE/BV/SGS
Model Number: Best-1000-680
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: plastic film for naked machine
Delivery Time: 40-50 days
Supply Ability: 10 sets/month

1000-680 PLC K Span Roll Forming Machine Locking Roof Bending Seaming

Description
Product Name: 1000-680 K Q Span Roll Forming Machine Driven System: Chain
PLC: Delta Usage: Roof
Warranty: 2 Years Life Time: More Than 10 Years
High Light:

arch sheet roll forming machine

,

automatic roll forming machine

1000-680 K Q Span Roll Forming Machine/Locking Roof Bending Machine Seaming Machine

MAIN TECHNICAL SPECIFICATION
Size: 9000mm×2250mm×2300mm

Total weight: About 15000KG

Material of bending leaf: Stainless Steel

Thickness of bending leaf: 12mm

Cutting Material: Cr12MoV, Heat treatment

Cutting type: Hydraulic / Mechanical controlling cutting

Total motor power: 18.5KW

Forming Power: 7.5KWB

ending Power: 4.0KW

Cutting Power: 4.0KW

Conical Power: 3.0KW

Material of rollers: 45# steel, quenched HRC 58-62

Material of shafts: 45# steel, adjusted

Step of rollers: 13

Applicable Span: 32m max.

Width of the Panel: Feeding width: 1000mm

Finished width: 680mm

The depth of the groove: 223mm

Operating factor of the panel: 68%

Thickness of the Panel: 0.8-1.5mm

Working Speed: Straight Sheet: 15m/min

Arch Sheet: 13m/minSeaming: 6m/min

Electric Standard: 380V / 50 HZ / 3 PHASES or according to your requirement

Controlling system: PLC

Machine component :







Machine component

5 ton passive de-coiler1 set
Main roll forming machine1 set
Control box1 unit
Hydraulic station1 unit
Out table2 units
Arch machine1 unit
Sew machine1 unit
Portable wheels2 unit
Spare parts



K Span Roll Forming Machine is a color-coated steel plate that is cold-rolled into various wave-shaped pressed plates. It is suitable for industrial and civil buildings, warehouses, special buildings, roofs, walls and interior and exterior wall decoration of large-span steel structures. It has the characteristics of light weight, high strength, rich color, convenient and quick construction, anti-seismic, fireproof, rainproof, long life and maintenance-free. It has been widely used.


Online Service.

We will give you fast and easy online access to your Installed Base to order your original spare parts and explore the Options & Upgrades relevant for your line.
It is a user-friendly interface, available 24/7, in 9 languages, and is your one-stop online shopping. Designed to make your life easier in your day to day business, it will help you to improve your line and maintain its performance.


RFQ

1. Are you manufactures?
100% yes, we are the manufacture who have experience on k span machine.The company is not far from Beijing, we welcome you to visit us anytime.

2. How to contact us?
By e-mail, phones calls or even plan a visit.


3. What is the warranty?
Of all the main parts are processed by ourselves , so we offer the permanent guarantee for them.

4. What about the trainning?
For most new users are concerned with trainning.We will train your people if you send them to our facotory or we send technicans to you for instruction. The machine is easy operation and learning.
