Product Details:
|
| Name: | Building Material Glazed Wave Roof Tile Roll Forming Making Machine PLC Control | Certification: | CE/ISO |
|---|---|---|---|
| Tile Type: | Colored Steel | Voltage: | 380V 50Hz 3phases |
| Speed: | 8-12m/min | Place Of Origin: | Hebei,China |
| Key Selling Points: | Long Service Life | Way Of Drive: | 1.0 Inch Single Chain |
| Roller Material: | 45# Steel | Control System: | PLC Control |
| High Light: | roof panel roll forming machine,steel roof tile forming machine |
||
Building Material Glazed Wave Roof Tile Roll Forming Making Machine PLC Control
1. Working Flow:
Decoiler--feeding materil--roll formng--pressing and cutting--output table
2. Component:
|
COMPONENT FOR Roof Sheet Glazed Tiles Roll Forming Machine
|
|||
|
Name
|
Quantity
|
Units
|
|
|
Decoiler
|
1
|
Set
|
|
|
Main Machine
|
Feeding device
|
1
|
Set
|
|
Roll forming system
|
1
|
Set
|
|
|
Cut Equipment
|
1
|
Set
|
|
|
Hydraulic system
|
1
|
Set
|
|
|
Electric control system
|
1
|
Set
|
|
|
Supporter/Automatic Stacker
|
1
|
Set
|
|
3. Parameter
|
Technical parameters: |
||
|
1 |
Cutting&Hydraulic type |
Double guide pillar |
|
2 |
Hydraulic motor power |
3kw,4kw |
|
3 |
Hydraulic Pressure |
10-12MPa |
|
4 |
Voltage |
380V /3phase/ 50 HZ (or as your requirement) |
|
5 |
Cutting drive |
Decelerating motor + Chain drive gear all by high-frequency |
|
6 |
Control System |
Panasonic /Siemens / Schneider / Delta PLC |
|
7 |
Length measurement |
Encoder |
|
8 |
Main Frame |
300mm/350mm H-Beam or 350mm |
|
9 |
Backboard Thickness |
17mm/200mm |
|
10 |
Chain Size |
1inch/2inch |
|
11 |
Feeding Material |
Better as your drawing or from our designer |
|
12 |
Feeding Thickness |
0.18mm-0.8mm |
|
13 |
Effective width |
Better as your drawing or from our designer |
|
14 |
Productivity |
12-20/min |
|
15 |
Roll Station |
14rows& 14(according to different design) |
|
16 |
Roller Diameter |
70mm/75mm(depend on different design) |
|
17 |
Roller material |
45# steel |
|
18 |
Cutter material |
Cr12 mould steel heat-treated hardness of HRC = 60-62 degrees |
|
19 |
Total Weight |
2t-12t |
|
20 |
Package of machine |
Waterproofing membrane, standard export packing |
|
21 |
ridge cap roll forming machine of the Components |
Manual decoiler-------------------1 set(5t) Guiding Platform------------------1 set Coil Strip Leveler------------------1 set Main Machine of Roll Forming------1 set Hydraulic Station------------------1 set Supporter Table-------------------1 set Coil Strip Leveler------------------1 set |
|
23 |
ridge cap roll forming machine machine technical parameters can be changed, according to customer's need. |
|
