Product Details:
|
| Product Name: | CE Standard Fully Hat Purlin Roll Forming Machine With Competitive Price | Control System: | PLC |
|---|---|---|---|
| Cutting Type: | Flying Saw | Warranty: | 2 Years |
| Lifetime: | 10years | Roller Material: | Cr12 Mov |
| Shaft Material: | 45#steel | CE Standard Fully Hat Purlin Roll Forming Machine With Competitive Price: | 380V, 50Hz, 3Phase |
| High Light: | c channel roll forming machine,steel frame roll forming machine |
||
The advantages of top hap purlin machine are as follows:
1. Assembly process meets export standards, body frame and sideboard are spray-painted,
other parts are finished through baking/chroming/galvanizing/blackening respectively, then unified assembly. After surface treatment,
not only extend lifetime, but also improve overall appearance.
2. Manufactured from 45# steel, CNC lathes, Heat Treatment, hard Chrome Coated, surface with mirror treatment (more wearable and rust-free)
3. Rolling shafts are with precision machined. Solid core, 75mm, the material thickness increased to 0.8mm
4. Hydraulic cutting device, make the cutting smooth and neat.
5. Easy operation, low maintenance cost
Working flow
Decoiler------feeding------roll forming-------cut to length-----output table
Profile Drawing
Machine Components
| Name | Quantity(set) |
| De-coiler | 1 |
| Feeding guiding Device | 1 |
| Roll Forming Part | 1 |
| Hydraulic cutting Device | 1 |
| Computer control box | 1 |
| Hydraulic System | 1 |
| Run-out table | 1 |
Parameter
| Configurations | Manual Uncoiler ,Guiding Platform ,Coil Strip Leveler ,Main Body Of Roll Forming Machine, Electro-Motor, Hole-Punch Device ,Cutting Device ,Hydraulic Station ,PLC Control. |
| Control System | PLC Panasonic Inverter |
| Main Frame | 350mm H-Beam |
| Main Power | 5.5 kw |
| Pump Power | 3kw |
| Power Supply | 3-Phase,380V,50Hz |
| Forming Speed | 12-14m/min |
| Hydraulic Pressure | 18-20MPa |
| Forming Size | 80mm |
| Feeding Thickness | 1.5-3.2mm |
| Roller Station | 12 Stands |
| Roller Diameter | 60mm |
| Backboard Thickness | 16mm |
| Chain Size | 66mm |
| Cutter Standard | Cr12 |
| Roller Standard | Cr12 |
| Cr-Plating Size | 0.05mm |
| Overall Size | 9500×1400×1350mm |
| Total Weight | 6T |
| Working conditions | |
| 1.Machine size | 10m x 1.2m (L XW) |
| 2.Working size | 20m x 2.5m (LXW) |
| 3.Power supply | 8.5kw |
| 4.Frequency | 50-60HZ |
| 5.Wires/cables | 4-6mm²(length according to workshop) |
| 6. Labor cost | 2 workers |
| 7. Tools | Spanners and screwdriver |
| 8.Lift device | 3-5t forklift or crane |
