Traffic Barrier Crash Highway Guardrail Roll Forming Machine Hydraulic Cutting
1. Description of w beam two or three waves highway guardrail sheet cold roll forming machine:
Guard rail roll forming machine is used to produce guard rails or crash barriers. Hot rolled, galvanized or other steel sheet and coil is suitable roll forming materials for this machine. This machine is mainly made up of loading coil car, exit looping kit, roll former with tooling, automatic stacking device, flying cut-off machine, servo roll feeder, leveler, loading coil car, etc. The finished products are widely used on highway, expressway and other public places to prevent different kinds of accidents and improve safety. They can also be used as fence for livestock farms and other places.
2. Main parameters of highway guardrail machine
|Main parameters of highway guardrail machine
||Suitable to process
||Color steel plate, galvanized sheet,aluminum coils and etc.
17 rows forming
7 roller leveling
||Thickness of feeding material
||45# forging steel
||Diameter of shaft
||Cutting tool material:
||GCr12 with quenched treatment 60-62°C
||380V 50Hz 3phases
||Wall thickness of main forming machine
||14mm steel plate
||Main forming machine body
||300 mm H steel
3. Processing technique and deployment
Processes: 10T Hydraulic de-coiler—Leveling device--Punching station--Roll forming machine—PLC system—Hydraulic system-Cutter—Output table
4. Technical Specification
(1)Hydraulic de-coiler: max.capacity: 10T;
(2) Hydraulic System: Power of the oil pump: 11kw Hydraulic oil :40#
(3)Computer control cabinet :
It adopts Delta PLC to control(PLC brand can be changed as your requirement).
The target piece length is adjustable and digit of it can be adjusted
Computed mode has two modes: automatic and manual one.
Processing precision : within 1.00mm
It contains liquid crystal screen, programmer, transformer for the electronic machines and kits of every part.
Reducer is Xingxing Cycloid which works stably and no noise
(4) Counter: One counter gauges length, pulses, and decides length
(5) Output table: It used to load the forming plate
