Two Waves Cold Rolled 15kw Highway Guardrail Machine

Two Waves Cold Rolled 15kw Highway Guardrail Machine
Two Waves Cold Rolled 15kw Highway Guardrail Machine

Large Image :  Two Waves Cold Rolled 15kw Highway Guardrail Machine

Product Details:
Place of Origin: CHINA
Brand Name: BEST
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD$30000---60000
Delivery Time: 30 work days
Payment Terms: L/C, T/T
Supply Ability: 20 sets/month

Two Waves Cold Rolled 15kw Highway Guardrail Machine

Description
After-sales Service Provided: Engineers Available To Service Machinery Overseas Warranty: 1 Year
Weight: Around 10.0 Tons (depend On Final Design) Voltage: 380V 50Hz 3phases
Condition: New Color: Customers Requirement
High Light:

cold rolled highway guardrail machine

,

two waves highway guardrail machine

,

15kw highway guardrail machine

We are a reputable and reliable manufacturer specializing in Guardrail Installation Machine, Guardrail

Repairing Machine, Guardrail Maintenance Machine and other road safety products for many years.

As a contractor of highway guardrails, we not only supply the Highway Guardrails, but also do the installation

and maintenance of guardrails by our construction team with our Guardrail Machines.

Our Highway Guardrail Installation and Repairing Machines have been exported to Central & South America,

Middle East, East Europe, Southeast Asia, Africa etc.

Our Highway Guardrail Installation and Repairing Machines include YZ Series Pile Drivers, YW Series Pile

Drivers, TDB Series Pile Drivers, YC Series Crawler Pile Drivers, Guardrail Repairing Machines etc.





Introduction

Two waves Cold Rolled highway guardrail roll Forming Machine



This equipment is primarily used in the repair of dented and warped guardrails. Repair is achieved by utilizing 7 rollers (9 rollers is available if you need) for rolling correction, multi-rolling straightening and auxiliary devices to repair damaged guardrails (not including inner strain and tears), to gradually eliminate dents, warping and other types of deformation making guardrails available for recycling and reuse. This guardrail repair straightening product is second generation and is presently the ideal highway maintenance device and the ideal device for use by machinery manufacturers given its stable performance, convenient control and it's bright economic prospects.

Two Waves Cold Rolled 15kw Highway Guardrail Machine 0









Guardrail Repair Process:



This equipment makes use of cold form shaping through a three gantry framed archway and a mold roller of shaft diameter 80mm through a mold produced from high quality steel. The entire guardrail’s mold shape and technical requirements are in compliance with national standards form 31085, Euro-American style crash barrier section size, (note, if entire sections of Japanese style guardrails are needed, only the mold needs to be exchanged, the mold can then correct the entire section). Damaged and deformed guardrails, after undergoing four roll reconstructions, are pushed into the back of the four roll straightening leveling system and the entire section is continuously extruded for the correction of warped deformations and finally passes completely through the system with dents removed and the rail leveled. By shape correction, guardrails may be returned to its original state and technical requirements resulting in satisfactory usage and economic benefits by users





Power and Transmission:



This device makes use of a 15-30KW main drive motor, coupled with JZQ-500 gear transmission to allocate each gear drive to a correction track and by usage of variable transmission speed, gives the system completely reasonable reliability. Also, the device is equipped with 2 meter long front and 4 meter long rear end benches, with a safety protection cover along the transmission gear line.





Usage



This device repairs warps and deformations of the 31085 guardrail (not including inner strain, tears or other serious damages) by passing it firstly through four multi-rollers for straightening to bend and twist different deformations back into their original shape, and performance for re-use. We adopt repair methods based on the classification of the damages. Guardrail repair is divided into two categories: heavy and light warping (visualization). The repairing of heavy warping must be repaired before four-point roll-straightening, the upper and lower rollers mold gap must be increased to 4mm by adjusting the screw of the main machine, (factory standard gap 3mm). The machine can then begin to correct the heavily warped guardrails to return them to their original shape and then they will be corrected along with light warped (the gap must be restored to 3mm) guardrails-one time correction will be complete. If the implementation of repair methods based on the guardrail’s damage classification isn’t carried out, there will be a subsequent increase in equipment wear thus shortening the machine’s operational life.



Main Technical Specifications



Type RS110 RS210
G.W. 5000 KG 6500 KG
Main Machine Size 3300×2500×1120mm 3300×2300×1500 mm
Size of Working Platform 450×500×3500 mm 450*850*3500 mm
450×500×2000 mm 450*850*2000 mm

Thickness of steel plate for fixing all the

machines and accessories

-- 30 mm
Type of Diesel Generator -- YZZ115ZD
Power of Diesel Generator -- 30 KW
Output Voltage -- 380-400 V
Output Current -- 54 A
Frequency -- 50 HZ
Rectifying Speed Theoretical Value: 1 piece/min.
Roller Quantity 7 pieces
Roller Diameter Φ80mm
Rated Power 15-30 KW
Speed Adjusting Range 3-25 r/min.
Rated Revolving Speed 132-1320 r/min.
Working Circumstance Height above the sea level≤1500 m
Temperature of circumstance:-20℃~+45℃
Relative humidity≤98%





Related Product



Equipment list


1. Front two meters working material platform
2. Guardrail Repair Machine Host
3. 31085 guardrail repair mold one set (already installed)
4 . Behind 3.2 m working feeding platform
5. 15KW speed motor
6. 500 type reducer
7. Electrical control Casing (governor-pack)
8. 45 One of the open-end Wrenches
9. One (1) 12" wrench
10. One (1) Manual
11. One (1) 8mm hex wrench







Equipment Installation





In the installation of the system, the end section must have more than five meter distance between it and workers to ensure safety from the guardrails. After installing the device base (it is fixed by welded steel or concrete footing anchored to the floor by bolts), connect the power supply, add gear oil and after 5 minutes of no abnormal sounds (wires and gear oil should be purchased by buyer), repairs can be carried out.
