Product Details:
|
| Type: | Tile Forming Machine | Tile Type: | Steel, Glazed Steel |
|---|---|---|---|
| Production Capacity: | 8-12m/min | Rolling Thinckness: | 0.5-1.2mm |
| Condition: | New | Use: | Door |
| High Light: | slats cnc roll forming machine,1.2mm slats roll forming machine,glazed cnc roll forming machine |
||
Several sections of steel, a type of section formed by cold rolling of strip steel or plate, widely used in purlins for agricultural greenhouses, housing models, solar brackets, large steel structure stadium purlins, with long service life, beautiful appearance, convenient installation, and load-bearing capacity Great features.
|
1 |
Suitable material |
Color steel sheet ,galvanized steel sheet, aluminium sheet |
|
2 |
Width of material |
333mm or customized |
|
6 |
Thickness of material |
0.4-0.6mm, customized |
|
2 |
Working speed |
8-10m/min, can be 20m/min |
|
3 |
Main motor power |
4kw with cycloidal reducer |
|
4 |
Hydraulic station power |
4kw |
|
5 |
Electrical control system |
PLC control system |
|
7 |
Shaft diameter |
65mm |
|
8 |
Roller station |
17 rows |
|
10 |
Dimension |
7800x1150x1510mm |
|
11 |
Weight |
About 3.6T |
|
12 |
Voltage |
380V 3phase 50HZ or as the customer's requirements |
|
13 |
Material of roller |
High grade 45# forged steel plated with hard chrome plating |
|
14 |
Material of cutting |
Cr12 mould steel with quenched treatment |
|
15 |
Working time |
Can be 24 hours |
|
16 |
Workers |
1-2 only |
Note:Above parameters are standard,we can design and make some change according to your requirement.
Forming structure composition
The machine is mainly composed of passive loading rack, leveling device, punching device, rear cutting device, hydraulic station, computer control system, etc.
Easy operation
The finished product of one-key type-changing c-shaped steel machine has good tensile, bending and compression performance. Good straightness, high degree of automation, quick and convenient installation
Good stability
Such as the roof load-bearing load and wall support of factory buildings, warehouses, hangars, exhibition halls, theaters, stadiums, market flower sheds
Main components
It can produce cold-formed steels with a variety of sections and different materials with uniform wall thickness, but complex cross-sectional shapes, which are difficult to produce by general hot rolling methods.
(3).Technical Detail
A Sheet Specifications
| 1 | Coil Type | PPGI GI |
| 2 | Width | 450mm |
| 3 | Thickness | 0.8-2mm |
| 4 | Yield stress | Q235 |
| 5 | Effective | 300mm |
B Components Details
| Roller Material | High grade 45# steel. Hard chrome plating, 0.05mm. |
| Main Frame | 350# steel. More stable and no shaking. |
| Middle Plate |
16mm. We use thicker plates to ensure stability of our products. |
| Forming Steps | 15, according to the drawing. |
| Shaft Material | Φ70 mm, high grade 45# steel. |
|
Treating process: tempering- finish turning, high rigidity, hard to deform. |
|
|
Cutting Blade Material |
Cr12, hardness HRC60-62. |
| Treating process: heat treatment- plane abrasion- wire electrode cutting. |
C. Electric Components
| Suitable Power | 380V, 50 Hz, 3 phase or according to your need. |
| Screen | 7 inch touch screen, easy to operate. |
| PLC | Delta DVP 14ES |
|
well-adapted to various conditions, such as moisture, electromagnetic disturbance. |
|
| Frequency Converter |
Delta VFD-M. It has the advantage of slowing down before cutting, to ensure the length accuracy (±1mm, far better than industrial standard ±3mm). |
|
Length Measurement Device |
Omron, made in Japan. |
| It features with high accuracy and stability. |
|
(1)The general machine parameter |
||
|
Suitable roll forming material |
Color steel sheet or galvanized steel sheet |
|
|
Thickness |
0.5-1.2mm |
|
|
Effective width |
300/400±3mm |
|
|
Feeding width |
398/498mm |
|
|
Frame design |
Wall-plate-frame-design /Strong-stand-frame-design |
|
|
Roll stages |
20 stages |
|
|
Material of forming roller |
40Cr, CNC lathes, Hard Chrome Coated |
|
|
Shafts Diameter |
Φ75mm |
|
|
Main motor power |
7.5KW, frequency speed control |
|
|
Max. Line speed of roll former |
12m/min (Higher speed is available, depends on the specification required by the buyer) |
|
|
Hydraulic group power |
4 KW |
|
|
Material of cutting blade |
Cr12, heat treatment |
|
|
Electric Standard |
380V /50Hz/3PH or as the customer's requirements |
|
|
Machine Dimensions |
8750mm×1380mm×1400mm |
|
|
Major Color of Machine Painted |
RAL 5015 (Blue) or as per customer’s requirements |
|
|
(2) PLC Control system |
||
|
PLC |
Siemens brand (ABB brand is available if required) |
|
|
Touch Screen |
Siemens brand (ABB brand is available if required) |
|
|
Inverter |
Schneider brand (ABB brand is available if required) |
|
|
Encoder |
Omron brand |
|
|
(3)Product rack |
||
|
Description |
un-powered, 3 units |
|
|
(4)Option: CE certificate Pl refer to the attached pictures for details |
||
|
(5) Service after sell |
||
|
In correct operation & maintaining, the machine is guaranteed for one year since leaving our factory excludes the electric elements. Installation: (1) If installation is needed, Liming (the seller) will dispatch technician to the buyer’s factory abroad to assist regulating the machine with charge free. The buyer should assist Liming to get the Chinese technician's visa and should pay for the roundtrip air ticket and the local accommodation. (2) If installation is needed, the buyer shall make the following preparation before arrival of technicians. a) Position the machine in the buyer’s factory. b) Prepare necessary electric wiring. c) Prepare material of trial running. d) Provide labors for assistance and installation during installation. e) If possible, One Chinese-speaking interpreter so that the communication between the buyer and seller’s technician will go smoothly. |
||
