25m/Min Drywall Stud And Track Roll Forming Machine For Light Steel Track

Drywall Stud And Track Roll Forming Machine / Roll Forming Equipment For Light Steel Trac

5. Specification of Components

(1) 3T Manual Un-coiler

• Adopt automatic hydraulic system for expand
• Width of feeding: 350mm
• Capability: 3 Ton
• Bound of expand &fight: 380mm—520mm
• Mode of expand &fight: inner expand &fight by manual
• Way of feeding: manual

(2) Main Roll Forming Machine

• Roller material:ASTM1045 chrome plated surface with chrome
• Shaft diameter: ￠56mm material: SAE1045 with quenching and tempering
• (3) Machine Structure
• Main frame by 350H beam welding
• Machine structure: Wire-electrode cuttin

(4) Track cutting system

• Machine adopt track cutting system, Non-stop
• Cutting power by hydraulic, 7.5KW
• Track cutting by servo motor, power in 3.0KW
• Cutting after forming: Cut the sheet after roll forming to required length
• Cutting motion: The main machine is NON-stop when cutting
• Material of blade:Cr12 with heat treatment 58-60°

(5) Computer Control Cabinet

• Programmable setting of profile length and quantity
• Operating system language: English and Chinese
• Computer used to control length & quantity. Machine will automatically cut to length and stop when required quantity is achieved

• PLC: Panasonic or customerizatio
• Technical data of metal stud and track roll forming machine

Layout drawing of machine

Uncoiling the sheet ---- Sheet guiding ----- Roll forming ---- post cutting ---- Panels to

Our Roll Forming Machine’s advantages

1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .to protect surface shiniing and strong

2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.and hardness 60 degree.

3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.

4. High precision: shafts for rollers are tooled by grinding machine. Rollers are CNC processed to ensure precision performance.

5 .automatic PLC : introduced Mitsubishi PLC with touch screen ,inverter,transformer.

6. powerful driving system: big inch train,or gear box driving system.

6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.

After Service

a. One year guarantee for whole machine.

b. 24 hours technical support by email or calling

c. If there is any problem found of the machine, we will repair it for free in one year.
