Product Name: Steel Profile Roll Top Ridge Cap Roll Forming Machine Popular In Kenya Material: PPGI
Bottom Frame: 360H Steel Machine Dimention: 6.5mx1.4mx1.4m
Machine Power: 3kw+4kw Driven System: Chain Or Gear Box
High Light:

gearbox driven metal roofing machine

,

ppgi ridge cap roll forming machine

,

gearbox ridge cap roll forming machine

Steel Profile Roll Top Ridge Cap Roll Forming Machine Popular in Kenya



Machine components


No. Name Qty
1. De-coiler 1 Set
2. Roll Forming Machine 1 Set
3. Pressing Device 1 Set
4. Hydraulic Cutting Device 1 Set
5. PLC Control Box 1 Set
6. Hydraulic Pump 1 Set
7. Stacker 1 Set


Work flow:

Material feeder→Molding core→Hydraulic system→Automatic control system→Automatic shearing maechanism→Roll forming receiving tables



Parameter



Roll Forming Machine

Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is being stamped.
Length of the main part: About 8500 1650 1500 mm (L*W*H)
Weight of main part: 6.5 tons
Voltage : 380 V 50 HZ 3 PHASE(As customer’s need)
Roller fixer : Middle plate
Frame : 350 H steel welded
Drive mode: Chain
Material of rollers: 45# steel, surface hard chromium plating.
Material of shafts: 45# steel
Diameter of shafts: φ 70 mm
Number of rollers : 14 rollers
Main power: 5.5 kw



Cutter deive

Feature : Ensure stability, precision and cutting speed
It is used to make the step , the glazed tile's final formed.
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products. Function : Automatic cutting controlled by PLC
Material of blades : Cr 12 quenched
Power supply : Hydraulic power
Components: It contains one set of blade, one hydraulic tank and one cutter machine.



Hydraulic Station

It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job.
Hydraulic motor Power: 4 kw
Hydraulic oil: 46# hydraulic oil
Volume: 30 L
Components: The system includes a set of hydraulic tank , a set of hydraulic oil pump, two hydraulic pipes. and two sets of electromagnetism valves.



Control box
1. Adopted PLC , transducer, touch panel to ensure high speed with stability, precision and lifetime.
2. Voltage: 380V 50 HZ 3 PHASE (As customer’s need)
3. Language: English and Chinese
4. Automatic length measurement
5. Automatic quantity measurement
6. Length Tolerance: 3 m±1.5 mm
7. Length inaccuracy can be amended easily.
8. Unit of length: millimeter (switched on the control panel)
9. Computer operating panel: touching screen and button together.



Warranty

1. One year warranty, whole life technical support.
2. Installation & adjustment : We can take a video for the customer and the customer can also come to our factory, we can train customer how to install and adjust the machine.
3. Oversea service: the buyer should charge of visa, return ticket, food and accommodation overseas and USD50/person/day salary.
