Automatically Cutting Steel Roofing Profile Roofing Panel Sheet Roll Forming Machine for Sales

Large Image : Automatically Cutting Steel Roofing Profile Roofing Panel Sheet Roll Forming Machine for Sales

Product Details:

Place of Origin:	CHINA
Brand Name:	BEST
Certification:	CE
Model Number:	YX1020

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD6000--10000
Delivery Time:	30 work days
Payment Terms:	L/C, T/T
Supply Ability:	20 sets/month

Contact Now

Automatically Cutting Steel Roofing Profile Roofing Panel Sheet Roll Forming Machine for Sales

Description

Voltage:	380V 50Hz 3 Phases	Condition:	New
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Control System:	PLC(imported Brand)
Warranty:	1 Year	Raw Material:	Color Steel Sheet
Highlight:	automatic steel roofing panel machine , roofing sheet roll forming equipment , steel profile cutting forming machine

Automatically Cutting Steel Roofing Profile Roofing Panel Sheet Roll Forming Machine

Attribute	Value
Voltage	380V 50Hz 3 phases
Condition	New
After-sales service provided	Engineers available to service machinery overseas
Control system	PLC (imported Brand)
Warranty	1 year
Raw material	Color Steel Sheet

Product Description

This automatically cutting steel roofing profile roll forming machine is designed for efficient production of high-quality roofing panels with precise cutting capabilities.

Technological Process

Decoiler → feeding → guide → roll forming → cut to length → run out table

Key Features

Professional engineering team skilled in Copra Software for precise forming diagram design
Heavy-duty stands for robust and strong machine construction
Pneumatic saw flying cut system for all profile types
Popular in supermarket construction projects across North and South America
Can supply complete accessory parts including rack machine, crossbar machine, and base machine

Machine Composition

Manual Uncoiler	1 unit
Control panel	1 unit
Roll forming main machine	1 unit
Cutting Device	1 unit
Manual out table	2 units

Equipment List

De-coiler (Manual)
Main roll forming machine (24 stand)
Hydraulic post cutoff unit
Hydraulic power pack
Back cutter
Lamination unit
Electrical control system

De-Coiler Specifications

Weight: 2500 kg
Capacity: 5000 kg max
Coil ID: 510 mm
Max coil width: 1450mm
Min coil width: 500 mm

Electrical Control System

PLC control mechanism for high accuracy length control
HMI 3x3 Touch color screen
Variable frequency Drive
Encoder system
Auto single piece system
Automatic machine length counting
Operator pendant for flexible operation

Terms & Conditions

50% Advance Payment, Full Payment after trial at our workshop
Free operator training
One year service (Ticket & Accommodation in your scope)
GST extra
Ex Factory Rate
Erection Charges will be Extra
Transportation Extra as actual

Applications

IBR Roofing Sheet, IBR Sheet, Metal roof, Steel roof, Metal roof wall panel, Steel roof wall panel, Metal roofing sheet, Steel roofing sheet, Metal roof panel, Steel roof panel, Beams, C beams, Step beams in supermarket construction.

Competitive Advantage

Dedicated machine for each profile type
Custom roll forming machines available based on customer drawings or samples

Technical Specifications

No.	Item	Description
1.	Coil width	Depend on your profiles
2.	Working speed	12-15m/min
3.	Roll station	about 16 - 24 stations
4.	Material of roller	Grade 45 steel, polished and coated with chrome
5.	Material of main shaft	45﹟ steel
6.	Diameter roller	70mm
7.	Main power	7.5KW
8.	Forming thickness	1.0mm zinc and color steel, 250Mpa-G550MPA
9.	Transmission	by single Chains 1.5inch
10.	Feeding and guide	Surface polished and coated with chrome
11.	Machine drive parts	Adopt protect cover
12.	Machine station	Adopt new station with chrome
13.	Size of main machine	7500x1500x1300(mm) L x W x H (1x40GP container)
14.	Weight	about 8000Kgs
15.	Color of machine	Blue (or customer specified)
16.	Machine legs	Four legs (made from metal) in 350mm

Machine Specifications

Suitable for rolling	pre-painted galvanized steel 0.3~0.8mm thick
Cycle Time	15m/min
Cut-off System	4kW Hydraulic Cutting
Power	19.5kW
Dimensions	11,000 x 1,900 x 1,600mm
Forming Stations	22 stations

For more information about steel roof panel profiles, please contact us!
