Hydraulic Pressing Ridge Cap Roll Forming Machine with High Grade 45# Steel and 15 Forming Steps

Large Image : Hydraulic Pressing Ridge Cap Roll Forming Machine with High Grade 45# Steel and 15 Forming Steps

Product Details:

Place of Origin:	CHINA
Brand Name:	BEST
Certification:	CE

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD6000--10000
Delivery Time:	30 work days
Payment Terms:	L/C,T/T
Supply Ability:	20 sets/month

Contact Now

Hydraulic Pressing Ridge Cap Roll Forming Machine with High Grade 45# Steel and 15 Forming Steps

Description

Name:	Hydraulic Pressing Ridge Cap Roll Forming Machine Roll Top Design	Key Word:	Steel Profile Ridge Cap Roll Forming Machine
Voltage:	380V 50Hz 3phases	Condition:	New
Color:	As For Your Respect	Control System:	PLC System
Thickness:	0.3-0.7mm	Shaft Material:	High Grade No.45 Forged
Highlight:	Hydraulic Pressing Ridge Cap Roll Forming Machine , High Grade 45# Steel Ridge Cap Roll Forming Machine , 15 Forming Steps Ridge Cap Roll Forming Machine

Hydraulic Pressing Ridge Cap Roll Forming Machine Roll Top Design

This roof ridge cap tile making machine features advanced technology for high efficiency and reliable performance in concrete product manufacturing.

Key Features

High-speed cylindrical tile molding with production capacity of 6-9 pieces per minute
PLC automatic control system (Mitsubishi technology) with hydraulic pneumatic operation
Semi-circular guide rail design for enhanced stability and wear resistance
Main oil cylinder and four-cylinder orientation system improves equipment stability and mold longevity
Filter press type molding produces products with beautiful structure, high density, and precise dimensions
Multi-purpose functionality - can produce various tile types by replacing molds

Technical Specifications

Sheet Specifications

Parameter	Specification
Coil Type	PPGI GI
Width	500mm
Thickness	0.3-0.8mm
Yield stress	Q235
Effective	312mm

Machine Components

Roller Material:

High grade 45# steel with hard chrome plating (0.05mm)

Main Frame:

350# steel for maximum stability with no shaking

Middle Plate:

16mm thickness for enhanced product stability

Forming Steps:

15 steps according to technical drawings

Shaft Material:

Φ70 mm high grade 45# steel with tempering-finish turning treatment for high rigidity

Cutting Blade Material:

Cr12 steel (HRC60-62 hardness) with heat treatment and precision cutting process

Electrical Components

Component	Specification
Suitable Power	380V, 50 Hz, 3 phase (customizable)
Screen	7 inch touch screen for easy operation
PLC	Delta DVP 14ES with excellent environmental adaptability
Frequency Converter	Delta VFD-M with precision slowdown before cutting (±1mm accuracy)
Length Measurement Device	Omron (Japan) for high accuracy and stability
