Product Details:
|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Voltage: | 380V 50Hz 3phases |
|---|---|---|---|
| Condition: | New | Use: | Floor |
| Certification: | CE/ISO9001 | Warranty: | 2 Year |
| High Light: | panel roll forming machine,cold roll forming machine |
||
|
Suitable Material |
||
| Material Width | 1000/1250mm | |
| Effective Width | 600/850mm | |
| Material Thickness | 0.8-1.5mm | |
| Material Type | Galvanized Steel Strip,Prepainted Galvanised Steel | |
| Yeild Strength | 245Mpa | |
| Main Machine | ||
| Size shaft diameter | 95mm | |
| Wall Panel Thickness | 18mm | |
| Base Specification | H446*199 | |
| Main Motor | 37KW hydraulic system | |
| Forming Speed | 0-10m /min | |
| Forming Station | 33 Stations | |
| Blade Material | Cr12(Die Steel) | |
| Roller Material | 45# steel,CNC lathes, Heat Treated,hard Chrome Coated | |
| Mode of Speed Regulation | AC Inverter Speed Regulation | |
| Driving Mode | Reduction Motor + Chain Transmission | |
| Cutting Mode | Hydraulic Type,Post-cutting | |
| Cutting Motor | Hydra station/hydraulic motor | |
| Measuring Mode | Photoelectric Encoder | |
| Control Mode | PLC | |
| Operation Mode | Button+Touch Screen | |
| Voltage | 380V or 415V/50Hz/3Ph or 220V/60Hz/3Ph | |
| Dimension | 15 M*1.5M*1.3M | |
| Machine Weight | 16500KG(15500KG) | |
After sales service
1.In correct operation & maintaining, the machine is guaranteed for one year since leaving our factory excludes the electric elements (the spare parts stock are available for IMMDEIATELY SERVICE);
2.We offer technical support for the entire life of our machines. Our after-sale engineer is always online at 8:00-19:00 Chinese time on matter work time or holiday;
3. we will dispatch a technician to the factory abroad to install & regulate the machine also train workers at Clients’ place with extra cost.
| 1.Electric cutting device |
| Equipped with electric pre-cutting device, easily cut off and easier operating than manual cutting device. |
|
| 2.Rollers and Shafts |
|
Rollers manufactured from #45 steel, precision machined, Hard Chrome Coated; Shafts manufactured from #45 steel, Main Shaft Diameter=φ95/85mm, quenching and Hard Chrome Coated; tempering treated |
|
| 3.Main Machine |
|
Machine frame made from H450 type steel by welding; Side wall thickness: 18mm Hydraulic Driving, Gear chain transmission,26 forming stations Main Motor=37KW , Frequency speed control Forming speed approx.15 m/min Manufacturing process: spray painting for frame and wallboard; baking finishing/chroming/galvanizing/blackening for spare parts |
|
| 4.Embossing Device |
|
Manufactured from #45 steel, precision machined, tempering treated and Hard Chrome Coated; |
|
| 5.post-cutting system |
|
Hydraulic cutting system. Easily operating and incision flattening. Cutting blades made by high quality mold steel Cr12 with heat treatment Cutter frame made from high quality 30mm steel plate by welding |
|
| 6.Control System |
|
C purlin machine control box (Touch screen brand: WEINVIEW, Inverter brand: Finland VOCAN/Taiwan DELTA/ALPHA, Encoder brand: Japan Koyo/OMRON) |
|
| 7.Decoiler |
|
C purlin machine decoiler One set manual decoiler, Un-powered, manually control steel coil inner bore shrinkage and stop Max. feeding width: 500mm, coil ID range 470mm±30mm Capacity: Max. 3Ton |
|
| 8.C purlin exit rack |
| Un-powered, three units |
|
