Product Details:
|
| Material: | PPGI | Raw Material: | Steel Coil |
|---|---|---|---|
| Roller Material: | 45# Steel | Power(W): | 5.5+4KW |
| Warranty: | 2 Years | Use: | Floor |
| Voltage: | 380V 50Hz | Control System: | PLC ( Panasonic) |
| Thickness: | 0.3-1.2mm | Production Capacity: | 8-15m/min |
| High Light: | panel roll forming machine,cold roll forming machine |
||
Introduction and Guarantee :
1. This machine contains our experiences in 30 years and many times improvements by our engineers.
2. In our service, we support the equipments and profiles that customers really need and including our most sincere recommends.
3. Our roll forming machines are driven by chain in hydraulic system. Chain Drive System can save the power compare with other system. That also means that customers do not need to pay the extra power fee during production of steel panel.
Applications:
| Construction | Food Services | Lawn & Garden | Shelving |
| Automotive | Fencing | Lighting | Store Fixture |
| Display Industry | Furniture | Material Handling | Sporting Goods |
| Farming | HVAC | Mining | Transportation.etc |
Specifications:
| Suitable to process | colored steel plate,galvanized board |
| Width of the plate | 1200mm |
| Rollers | 30 groups |
| Rolling material | Forging steel 45# |
| Rolling galvanization thickness | 0.7-1.5mm |
| Material of the cutting blade | Cr12mov |
| Dimensions | Approx20m*1.6m*2m |
| Power | 22kw |
| Thickness of the plate | 0.7-1.5mm |
| productivity | 10m-15m/min |
| Diameter of the roller | 85mm |
| Weight | About 8T |
| Voltage | 380V 50Hz |
| Processing precision | Within 1.00mm |
| Equipment components |
Man-made uncoiler,roll forming machine, Compture control system Hydraulic control system Press foming cutting |
| Transportation | One complete equipment need one 40 feet container to hold |
Applications:
| Construction | Food Services | Lawn & Garden | Shelving |
| Automotive | Fencing | Lighting | Store Fixture |
| Display Industry | Furniture | Material Handling | Sporting Goods |
| Farming | HVAC | Mining | Transportation.etc |
Specifications:
| Suitable to process | colored steel plate, galvanized board |
| Width of the plate | 1250mm |
| Rollers | 18groups |
| Rolling material | Forging steel 45# |
| Rolling galvanization thickness | 0.3-0.8mm |
| Material of the cutting blade | Cr12mov |
| Dimensions | Approx9m*1.8m*1.5m |
| Power | 7.5kw |
| Thickness of the plate | 0.3-0.8mm |
| productivity | 15-30m/min |
| Diameter of the roller | 76mm |
| Weight | About 7T |
| Voltage | 380V 50Hz |
| Processing precision | Within 1.00mm |
| Equipment components |
Man-made uncoiler,roll forming machine, Compture control system Hydraulic control system Press foming cutting |
| Transportation | One complete equipment need one 40 feet container to hold |
Advantage:
1. We use Automatic control software to manage productive information.
2. Thanks to the High integrated network, the whole automatic control system has an improvement in automaticity.
3. High performance in operation, maintenance, and debugging. Easy to load and unload.
4. First in quality
5. First in time
6. First in price
7. First in services
