Product Details:
|
| Voltage: | 380V 50Hz 3phases | Condition: | New |
|---|---|---|---|
| New: | Colored Glaze Steel | Use: | Roof And Wall Or Any |
| Certification: | CE/ISO9001 | Control System: | PLC(imported Brand) |
| Tile Type: | Colored Glaze Steel | ||
| High Light: | cold roll forming machine,sheet roll forming machine |
||
| No. | item | Parameter(all is subject to our final design) | |
|
1
|
Suitable raw material | Type | Common galvanized & pre-painted steel |
| Yield strength | 235MPa(or other high strength steel) | ||
| Thickness(mm) | 0.4-0.7 | ||
| width(mm) | According to final design | ||
| 2 | Manual uncoiler’s capacity | Max.5tons | |
| 3 | Forming speed(m/min) | About 18-20m/min | |
| 4 | Main motor power(KW) | 5.5kw | |
| 5 | Hydraulic power(KW) | 3kw | |
| 6 | Forming roller groups | Around 19-20 groups | |
| 7 | Raw material of forming roller | High quality No.45 steel | |
| 8 | Raw material of cutting blade | Cr12mould steel with quenched treatment | |
| 9 | controlling system | Mitsubishi PLC& converter | |
| 10 | Suitable industrial voltage | According to your special requirement | |
| 11 | Machine weight | About 6.2tons | |
Machine’s Components
| 1 | 5 tons manual uncoiler with new brake design | 1set |
| 2 | Coil sheet guiding and adjust department | 1set |
| 3 | File covered department(optional) | 1set |
| 4 | Main roll forming systerm | 1set |
| 5 | Hydraulic cutting department | 1set |
| 6 | Hydraulic station | 1set |
| 7 | PLC control table | 1set |
| 8 | Final product runout table |
1set |
Working Flow of Roll Forming Machine
uncoiling the sheet---guiding the sheet---covering the film---roll forming---measuring the length---cutting the panel---panels to the support
Standard Profile drawing of product
Main Components
| Machine name | Quantity |
| 3 ton manual Decoiler | 1 set |
| Main roll forming machine | 1 set |
| Hydraulic station | 1 set |
| Hydraulic cutting device | 1 set |
| Finished poducts tabels | 2 stes |
| PLC control system |
Advantage for our PU roller shutter
1. Reasonable Price
2. High Quality
3. 12 Months Warranty
4. More Than 10 Years Experience
5. Durable
6. Reliable
machine picture
