Product Details:
|
| High Light: | 0.7MM deck floor roll forming machine,30KW deck floor roll forming machine,30KW deck roll forming machine |
||
|---|---|---|---|
1) Processing material: galvanized steel/colored steel coil
2) Material thickness: 0.7-1.2mm
3) Effective width: 914mm
4) Feeding width: 1250mm
5) Main motor power: 15kw+15kw
6) Pump power: 5.5kw
7) Roller Stations: 26 stands
8) Productivity: 0-12m/min
9) Roller material: bearing steel, with hard chrome plating
10) Shaft material: high grade NO.45 carbon wrought steel
11) Shaft diameter: 90mm
12) Cutting blade material: Cr12 mould steel with quenched treatment
13) Main frame: 450H Steel
14) Transmission Type: chain
15) Control system: Taiwan Delta PLC computer control system
16) Power supply: 380V, 3 Phase, 50Hz(or as per your request)
Manual decoiler→feeding device→main roll forming machine→cutting system→output table, two 15kw electric motors, hydraulic station with 5.5kw electric motor, PLC control system
1). Machine Price: Please contact us, we will try to give you good discount for starting our cooperation
2). Payment term: 30%TT should be paid as advance deposit, 70%TT before shipment
Or 100% LC at sight
3). Package: naked with simple plastic film and loaded in one 20-feet container
4). Delivery time: 50 working days after receipt of the deposit
5). Guarantee: 12 months. If any part of machine breaks, we will supply it for free.
6). After sales service
This producing line is maintained free of charge for 12 months. When the machine is used in China, we will install and debug the machine for free; if it is used at abroad, we will send the professional technician to debug. Buyers should take all the fees for technicians traveling abroad, and pay 100USDdayperson.
Our Floor Deck Roll Forming Machine are offered As per your requirement. our company has achieve great success in providing customer Services from all over the world with exilant machines featuring high technical content, optimized composition, reliable performance and easy operation. We are committed to providing quility machines for all customers with dedicated after-sales services.
Technical Specifications
Mandrel Uncoiler
Entry Gate
Entry gate will be provided for movement of sheet to roll former.
Main Base
The main base is MS fabricated structure and adequately ribbed to minimize the distortion. It is accurately machined on top and bottom surfaces the threaded holes are made on the bed for positioning the stands.
Mill stands (Station)
The stands are mounted on the bed of the machine the line alignment can be easily done due to guide ways arranged on the bed of the machine. Each forming head consists of a fixed housing and sliding type out board housing. The mill stands will be arranged to locate shafts mounted on taper bearings. For the top shafts the bearings are housed in the cartridge type bearing blocks. The bottom shaft bearings are located in the bored machined in the housings. The bottom arbors are fixed in position whereas the top arbors along with cartridge blocks could be raised or lowered in vertical guides machined in housings.
Roll shafts
The roll shafts dia. 70mm will be manufactured from quality steel and will be keyed to locate tooling.
Drive
The drive to the roll former will be by means of a chain. The main drive will be provided by means of 10 HP motor
Tooling
One set of Tooling with EN grade will be from imported material suitable for your machine as standard supply. The same is involved in operations like rough machining, keyway, rough profiling, profile machining and inspection with final template for above.
Cutting Unit (Hydro)
Hydraulically operated power pack along with cutting die with 3 HP electrical.
