Product Details:
|
| Tile Type: | Colored Glaze Steel | Voltage: | 380V 50Hz 3phases |
|---|---|---|---|
| Condition: | New | Weight: | 6T Roof Sheet Roll Forming Machine |
| 6T Roof Sheet Roll Forming Machine: | Roof/wall | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| High Light: | ppgi roof tile forming machine,ppgi double deck forming machine,0.3mm Roof Tile Forming Machine |
||
|
Suitable material
|
PPGI GI AL
|
|
Coil Width
|
914/925/1000/1200/1220/1250mm as custom
|
|
Thickness
|
0.3-0.8mm as custom
|
|
Power
|
380V 50Hz 3Phase as custom
|
|
Main motor
|
5.5KW Siemens
|
|
Hydraulic motor
|
4KW Siemens
|
|
Speed
|
15-30m/min
|
|
Forming stations
|
12-18 rows
|
|
Roller material
|
Cr12 steel with vacuum heat treatment HRC57°-60°
|
|
Shaft material
|
45# steel quenched and tempered
|
|
Shaft diameter
|
75mm
|
|
Chain
|
1.2 inch
|
|
Screem HMI
|
Delta , Touch Screen
|
|
PLC
|
Delta , Siemens
|
|
Processing precision
|
Within 1mm
|
|
Size
|
7.6m×1.5m×1.2m
|
|
Weight
|
4.5T
|
Description
Machine list:
| No. | Machine | Qty. | |
| 1 | Screw Loader For Extruder | 1set |
Main Tile Extrusion Line Ridge Tile Forming |
| 2 | Parallel Twin-Screw Extruder(PVC) | 1set | |
| 3 | Vacuum Loader And Drying Hopper | 1set | |
| 4 | Single Screw Extruder (ASA) | 1set | |
| 5 | Extrusion Mould And Distributor | 1set | |
| 6 | Calibration Mould And Trimming Device | 1set | |
| 7 | Haul Off Unit | 1set | |
| 8 | Cutter | 1set | |
| 9 | Stacker | 1set | |
| 10 | Ridge Tile Oven | 1set | |
| 11 | Ridge Tile Forming Machine And Mould | 1set | |
| 12 | Screw Loader For Mixer | 1set | Auxiliary Equipment |
| 13 | Mixer Unit | 1set | |
| 14 | Crusher | 1set | |
| 15 | Pulverizer | 1set |
Machine Advantage:
POLYTECH is involved in recycle plastic solution for 20 years. Now more and more countries suffer the dirty and mixing recycle plastic problems. If we use washing and cleaning way to separate it. It will be very costly for investment. So we consider some easy way to get the finished product properly and fast. It is very welcomed in developing countries, where the labor cost is not so higer.
Product Advantage:
WPC PP RECYCLE CORRUATED ROOF MACHINE is the best replacement to conventional asbestos, metal G.I. sheets . It is heat insulation, sound insulation, water resistance, chemical and alkali resistance, corrosion proof, fire retardant, eco friendly, easy to install and move, light weight as well as cost effective in installation (as less steel and less overlap), as per the efficiency and benefits it provides. It can save construction cost upto 50%.
Apart from its numerous benefits, its salient features include heat insulation upto 35% (highly energy efficient) and it can withstand temperature upto 70 degrees Celsius to - 40 degrees Celsius.
Work Flow:
Mixer for bottom layer (PP PE powder, CaCO3, CPE, PE-WAX, Stearic acid, Compound stabilizer, ACR, paraffin).
Extrusion process: twin-screw extruder -Extrusion Mould-surface embossing (Optional)-Forming machine-Haul-off-cutter-stacker-Main tile.
Oven-Ridge tile machine and mould-1set Ridge tile.
Crusher (waste material)-Pulverize—Reuse again for extrusion line.
